FLOWMAX Technologies 120 - Electronic Board Features

GENERAL INFORMATION
11
4.3
5.4
6.4
12.2
5.2
28.7
HO
CWI
G
HI HWO
1.9 3.1
4
1.2
12.2
28.7
4.4
7.3
4.4
1.9
12.3
1.9
4.9
2.7
3.2
2.2 Dimensions
LEGEND
HI
HEATING INLET
3/4" BSPP
HO
HEATING OUTLET
3/4" BSPP
G
GAS
1/2" NPT
CWI
COLD WATER INLET
1/2" BSPP
HWO
HOT WATER OUTLET
1/2" BSPP
SC
CONDENSATE DRAIN
0.98 in
