FLOWMAX Technologies 120 - Parameters table

REGULATION INSTRUCTIONS
41
5. REGULATING THE APPLIANCE
NOTES: P04 This parameter allows to modify the time the boiler takes (in heating mode) to reach the maximum power set.
P10, P11, and P12 These parameters are automatically set according to the output value set in Parameter P00.
P13 The maximum boiler power in heating mode, can be set according to the paragraph 5.5 "Heating output (Kw) - Fan frequency (Hz) diagram".
PARAMETER
No
TYPE OF OPERATION
PARAMETER
VALUE
FUNCTION
P00
Selects the model of boiler
00 (do not use)
01 (do not use)
02
03 (do not use)
04
05
06 (do not use)
00 - 13 KW
01 - 18 KW
02 - 25 KW – 85 304 BTU/hr
03 - 28 KW
04 - 34 KW – 116 013 BTU/hr
05 - 50 KW – 174 019 BTU/hr
06 - 100 KW
P01
Selects the type of boiler
00 (do not use)
01
02
03
(do not use)
04
05 (do not use)
00 – Instantaneous (w/ dual circuit Exchanger)
01 - Instantaneous Boiler (w/ secondary DHW Plate Exchanger)
02 - Storage Cylinder Boiler
03 - Boiler w comfort storage cylinder
04 - Comfort instantaneous boiler (w/ secondary DHW Plate Exchanger)
05 - Only Heating Boiler
P02
Selects the type of gas supplied
00 - 01
02 (do not use)
00 - Natural gas - 01 - LP Gas
02 - G25
P03
Sets the central heating temperature
00 - 01
Standard (30 - 80°C) - Reduced (25 - 45°C)
P04
Heating output rising time
00
01
02
03
04
0 Seconds (Disabled)
50 Seconds (Default)
100 Seconds
200 Seconds
400 Seconds
P05
Water hammer prevention function
00 - 01
Off - On
P06
DHW Priority Function
00 - 01
Off - On
P07
Central Heating Timer
00 - 90
Displayed in multiples of 5 seconds
(Default value 36 x 5 = 180”)
P08
Central heating Pump Overrun Timer
00 - 90
Displayed in multiples of 5 seconds
(Default value 36 x 5 = 180”)
P09
DHW / Storage Cylinder Pump Overrun
Timer
00 - 90
Displayed in multiples of 5 seconds
(Default value 18 x 5 = 90”)
P10
Sets the Minimum Fan Speed
(Domestic Mode)
(displayed in Hertz)
66 Ng / 60 Lp
55 Ng / 52 Lp
60 Ng / 60 Lp
Flowmax 90
Flowmax 120
Flowmax 170
P11
Sets the Maximum Fan Speed
(Domestic Mode)
(displayed in Hertz)
162 Ng / 159Lp
164 Ng / 155Lp
155 Ng / 143Lp
Flowmax 90
Flowmax 120
Flowmax 170
P12
Sets the Minimum Fan Speed
(Central Heating Mode)
(displayed in Hertz)
66 Ng / 60 Lp
55 Ng / 52 Lp
60 Ng / 60 Lp
Flowmax 90
Flowmax 120
Flowmax 170
P13
Sets the Maximum Fan Speed
(Central Heating Mode)
(displayed in Hertz)
162 Ng / 159Lp
164 Ng / 155Lp
155 Ng / 143Lp
Flowmax 90
Flowmax 120
Flowmax 170
P14
Sets the ignition Sequence
(displayed in Hertz)
90 Ng / 110 Lp
110 Ng / 130 Lp
90 Ng / 110 Lp
Flowmax 90
Flowmax 120
Flowmax 170
P15
Legionella prevention Function
(For storage boilers only)
00 - 01
Off - On
P16
Sets the climatic compensation curve
(w/outdoor temperature sensor only)
00 - 30
See the graph in the parameter setting explanation
P17
Sets the temperature measurement units
00 - 01
°C - °F
P18
Sets the 0-10v industrial bus piloting
00
01
02
Disabled
Flow temperature Control mode
Burner output control mode
P19
Central heating minimum set point
20 – 40
Displayed in °C
P20
Central heating maximum set point
40 – 88
Displayed in °C
P21
DHW maximum set point
45 – 75
Displayed in °C
P22
∆T set point T° flow / T° return
(w/modulating pump and return temperature
sensor connected only)
00
10 - 40
Disabled
Displayed in °C
P23
Modulating pump minimum speed
(w/modulating pump and return temperature
sensor connected only)
50 – 70 Displayed in percentage
P24
Modulating pump maximum speed
(w/modulating pump and return temperature
sensor connected only)
70 – 100
Displayed in percentage
P25
∆T timing T° flow / T° return
(w/modulating pump and return temperature
sensor connected only)
20 – 100
Displayed in seconds
