CPX, CPXR, CPXN and CPXP USER INSTRUCTIONS ENGLISH 71569117 02-10
Page 17 of 44 flowserve.com
5.2 Pump lubricants
5.2.1 Recommended oil lubricants
Oil Splash / force feed / purge oil mist lubrication
Viscosity cSt
@ 40 ºC
32 46 68
Oil temperature range *
-5 to 65 ºC
(23 to 149 ºF)
-5 to 78 ºC
(23 to 172 ºF)
-5 to 80 ºC
(23 to 176 ºF)
Centrifugal pump
lubrication
Designation to ISO 3448
and DIN51524 part 2
ISO VG 32
32 HLP
ISO VG 46
46 HLP
ISO VG 68
68 HLP
BP Castrol
†
Energol HLP-HM 32 Energol HLP-HM 46 Energol HLP-HM 68
ESSO
†
NUTO HP 32 NUTO HP 46 NUTO HP 68
ELF/Total
†
ELFOLNA DS 32
Azolla ZS 32
ELFOLNA DS 46
Azolla ZS 46
ELFOLNA DS 68
Azolla ZS 68
LSC (for oil mist)
LSO 32 (Synthetic oil) LSO 46 (Synthetic oil) LSO 68 (Synthetic oil)
ExxonMobil
†
Mobil DTE 24 Mobil DTE 25 Mobil DTE 26
Q8
†
Q8 Haydn 32 Q8 Haydn 46 Q8 Haydn 68
Shell
†
Shell Tellus 32 Shell Tellus 46 Shell Tellus 68
Chevron Texaco
†
Rando HD 32 Rando HD 46 Rando HD 68
Wintershall (BASF Group)
†
Wiolan HS32 Wiolan HS46 Wiolan HS68
Oil companies and
lubricants
Fuchs
†
Renolin CL 32 Renolin CL 46 Renolin CL 68
* Note that it normally takes 2 hours for bearing temperature to stabilize and the final temperature will depend on the ambient, r/min, pumpage
temperature and pump size. Also some oils have a greater viscosity index than the minimum acceptable of 95 (eg Mobil DTE13M) which may
extend the minimum temperature capability of the oil. Always check the grade capability where the ambient is less than -5 ºC (23 ºF).
†
Use LSC for oil mist. Oil parameters provide flash point >166 ºC (331 ºF), density >0.87 @ 15 ºC (59 ºF), pour point of -10 ºC (14 ºF) or lower.
5.2.2 Bearing sizes and capacities
Grease lubricated
medium duty bearings
Grease lubricated
heavy duty bearings
Grease lubricated bearing
capacities g (oz.)
Frame
size
Pump end Drive end Pump end Drive end* Pump end Drive end
1
2
3
4
6207 Z C3
6309 Z C3
6311 Z C3
6313 Z C3
3306 Z C3
3309 Z C3
3311 Z C3
3313 Z C3
6207 Z C3
6309 Z C3
6311 Z C3
6313 Z C3
7306 pair back-to-back
7309 pair back-to-back
7311 pair back-to-back
7313 pair back-to-back
6 (0.2.)
13 (0.5)
18 (0.6)
20 (0.7)
14 (0.5)
25 (0.9)
35 (1.2)
46 (1.6)
* Nilos ring fitted into bearing locknut [3712.2]
Oil lubricated
medium duty bearings
Oil lubricated
heavy duty bearings
Oil lubricated optional
heavy duty bearings
Frame
size
Pump end Drive end Pump end Drive end Pump end Drive end
Frame oil capacity
(approx.)
litre (fl.oz)
1
2
3
4
6207 C3
6309 C3
6311 C3
6313 C3
3306 C3
3309 C3
3311 C3
3313 C3
6207 C3
6309 C3
6311 C3
6313 C3
7306 pair back-to-back
7309 pair back-to-back
7311 pair back-to-back
7313 pair back-to-back
NUP 207 C3
NUP 309 C3
NUP 311 C3
NUP 313 C3
7306 pair back-to-back
7309 pair back-to-back
7311 pair back-to-back
7313 pair back-to-back
0.7 (23)
1.8 (61)
1.4 (47)
2.8 (95)
Note: the bearing sizes do not constitute a purchasing specification.
5.2.3 Recommended grease lubricants
Grease NLGI 2 * NLGI 3
Temp. range
-20 to +100 ºC
(-4 to +212 ºF)
-20 to +100 ºC
(-4 to +212 ºF)
Designation
acc. to DIN
KP2K-25 KP3K-20
BP
Energrease LS-EP2 Energrease LS-EP3
Elf
Multis EP2 Multis EP3
Fuchs
RENOLIT EP2 RENOLIT EP3
ESSO
Beacon EP2 Beacon EP3
Mobil
Mobilux EP2 Mobilux EP3 **
Q8
Rembrandt EP2 Rembrandt EP3
Shell
Alvania EP2 Alvania EP2
Texaco
Multifak EP2 Multifak EP3
SKF
LGEP 2
* NLGI 2 is an alternative grease and is not to be mixed with other
grades.
** Standard pre-packed grease for fitted antifriction bearings.
5.2.4 Recommended fill quantities
Refer to section 5.2.2, Bearing sizes and capacities.
5.2.5 Lubrication schedule
5.2.5.1 Oil lubricated bearings
Normal oil change intervals are 4 000 operating hours
or not more than 6 months. For pumps on hot service
or in severely damp or corrosive atmosphere, the oil
will require changing more frequently. Lubricant and
bearing temperature analysis can be useful in
optimizing lubricant change intervals.
The lubricating oil should be a high quality mineral oil
having foam inhibitors. Synthetic oils may also be
used if checks show that the rubber oil seals will not be
adversely affected.
