Flowserve HPX - Page 25

25
0
0.01
0.02
0.03
0.04
0.05
0.06
0.07
A B F1 F2
0.01
0.02
0.03
0.04
0.05
0.06
0.07
28 30 32 34 36 38 402624222018160 2 4 6 8 10 12 14
C C
Distance Over Motor Feet (in)
Pump
Hub
Clock
Readings
(in)
FIGURE 2
EXAMPLE 2
X-X
Y-Y
VERTICAL X - X HORIZONTAL Y - Y
A = TIR - 0.04 = - 0.02 A = TIR +0.012 = 0.006
B = TIR + 0.032 = + 0.016 B = TIR 0 = 0
At F1 Add 0.008 Shim At F1 Move to Far 0.012
At F2 remove 0.010 Shim At F2 Move to Far 0.039
0
0.01
0.02
0.03
0.04
0.05
0.06
0.07
A B F1 F2
0.01
0.02
0.03
0.04
0.05
0.06
0.07
28 30 32 34 36 38 402624222018160 2 4 6 8 10 12 14
C C
Distance Over Motor Feet (in)
Pump
Hub
Clock
Readings
(in)
FIGURE 2
EXAMPLE 3
Y-Y
X-X
VERTICAL X - X HORIZONTAL Y - Y
A = TIR + 0.036 = + 0.018 A = TIR - 0.060 = - 0.03
B = TIR - 0.024 = - 0.012 B = TIR + 0.046 = + 0.023
At F1 No Change At F1 Move to Far 0.009
At F2 Add 0.027 Shim At F2 Move to Near 0.0225
