Maintenance
If there is dust or filament on the PEI board, clean the PEI board
with water or alcohol before printing, the printed model will
adhere better to the PEI board.
Apply grease to the contact between the parallel arm and the wide
angle ball head,do it once every 15 days.
Adjust the belt tightness,do it once two every months.loosen the
two screws marked 1 and 2 in the photo,and then turn the belt
adjusting nut clockwise.When there is on gap between the
cylindrical gasket and the iron sheet tighten screws 1 and 2 .
Squeeze the grease onto the optical axis on both sides of the linear
guide,then slide the slider up and down to the spread the grease
evenly ,do it once every 15 days.
1
2
Belt Adjustment Nut
Flsun V400 , Amazing Speed!
30
