Assembly Instructions
2
Take out shells and place them vertically on the
desktop.The top shell " Flsun" logo and the QR
code are in the same direction.
Plug the motor cable before putting the motor into the
top shell. Install the 8*M5 screws on both ends of the
axis . Install the other two axis in the same way.
Note the one-to-one
correspondence
between motor and
motor lines X, Y and Z
Install the parallel on the slider.
Pass the straightened cable through the inside of
the Y-axis,insert the connector into the bottom
shell socket
Flsun V400 , Amazing Speed!
7
