Fluidmaster S2DBL User Manual

1
Z
4.4
P
18
17
16
15
14
13
12
11
10
9
8
7
6
H
G
I
J
Important: Attach the
end of rell hose to
nipple on Dual Flush
Valve as shown in
picture. Make sure both
tubes are clear of ll
valve and ush valve
operation. Ensure hose
clamp is secure.
Slide rubber gasket (P) onto threaded
end of ush valve. Use old gasket if
supplied new gasket does not t.
Secure tank to bowl with bolts (G), rubber
washers (H) brass washers (I) and hex nut (J).
Tank should be level after it has been installed.
NOTE: DO NOT over-tighten. May break tank.
Nut will not be used with all toilets.
www.uidmaster.com
8
4.3
Step 4: Reassemble
Secure rell hose
4.1 4.2
Prepare
Replace
