Fluidwell F116-P - Page 54

FW_F116-P_M_v2201-01_EN.docx
Page 54
PDU
ADDRESS
REGISTER
VARIABLE
DISPLAY
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 64
[h] 0x040
40065
function
1
R/W
uint16
0: total
1: flow rate
2=all
[d] 67
[h] 0x043
40068
backlight brightness
1
R/W
uint16
0: off
1: 20%
2: 40%
3: 60%
4: 80%
5: 100%
[d] 140
[h] 0x08C
40141
calculate
1
R/W
0=differential
1=add
[d] 73
[h] 0x049
40074
measurement
1
R/W
uint16
0: bi-direct
1: not negative
2: threshold
3: stationary
[d] 77
[h] 0x04D
40078
stationary flow rate
2
R/W
uint32
0...9999999
Representation: 0.000000…9999999
[d] 44
[h] 0x02C
40045
stationary total
2
R/W
uint32
0...9999999
Representation: 0.000000…9999999
PDU
ADDRESS
REGISTER
VARIABLE
POWER MANAGEMENT
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 80
[h] 0x050
40081
LCD update time
1
R/W
uint16
0=fast
1=1sec
2=3sec
3=15sec
4=30sec
5=off
[d] 81
[h] 0x051
40082
power mode
1
R/W
uint16
0=operational
1=shelf
PDU
ADDRESS
REGISTER
VARIABLE
FLOWMETER
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 96
[h] 0x060
40097
flowmeter signal A
1
R/W
uint16
0: npn
1: npn lp
2: reed
3: reed lp
4: pnp
5: pnp lp
6: namur
7: coil-hi
8: coil-lo
9: act. 8.1V
10: act. 12V
11: act. 24V
[d] 97
[h] 0x061
40098
flowmeter signal B
1
R/W
uint16
0: npn
1: npn lp
2: reed
3: reed lp
4: pnp
5: pnp lp
6: namur
7: coil-hi
8: coil-lo
9: act. 8.1V
10: act. 12V
11: act. 24V
PDU
ADDRESS
REGISTER
VARIABLE
ANALOG OUTPUT
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 112
[h] 0x070
40113
analog output
1
R/W
uint16
0=disable
1=enable
[d] 113
[h] 0x071
40114
minimum rate
2
R/W
uint32
0…9999999
Representation: unit, time, decimals
depending on variables 48, 49, 50
[d] 116
[h] 0x074
40117
maximum rate
2
R/W
uint32
0…9999999
Representation: unit, time, decimals
depending on variables 48, 49, 50
[d] 119
[h] 0x077
40120
cut off percentage
1
R/W
uint16
0...99
Representation: 0.0 – 9.9%
[d] 120
[h] 0x078
40121
tune minimum rate
1
R/W
uint16
0...9999
[d] 122
[h] 0x07A
40123
tune maximum rate
1
R/W
uInt16
0...9999
[d] 127
[h] 0x07F
40128
filter
1
R/W
uint16
1...99
PDU
ADDRESS
REGISTER
VARIABLE
PULSE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 135
[h] 0x087
40136
mode
1
r/w
uint16
0: not negative
1: separated
2: signed
[d] 128
[h] 0x080
40129
pulse width
1
R/W
uint16
0…9999, (0=disabled)
Representation: 0.000 – 9.999 sec
[d] 133
[h] 0x085
40134
decimals
1
R/W
uint16
0…3
[d] 130
[h] 0x082
40131
amount
2
R/W
uint32
1...9999999
Representation: 0.001 – 9999999
depending on variable 133
