PDU
ADDRESS
REGISTER
VARIABLE
COMMUNICATION
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 144
[h] 0x090
40145
speed (Baudrate)
1
R/W
uint16
0=1200
1=2400
2=4800
3=9600
[d] 145
[h] 0x091
40146
Modbus address
1
R/W
uint16
1…247
[d] 146
[h] 0x092
40147
Modbus mode
1
R/W
uint16
0: ASCII
1: RTU
2: OFF
[d] 147
[h] 0x093
40148
delay
1
R/W
uint16
delay between read and write command
0…65355
[d] 150
[h] 0x096
40151
index
1
R/W
uint16
used for indexed values
[d] 149
[h] 0x095
40150
Index use
1
R/W
uint16
0=
static
1=
increment
2=
decrement
[d] 25
[h] 0x019
40026
reboot
1
R/W
uint16
Returns 0 on read.
Write 0xA50F for unit restart
Write 0x5AF0 for factory settings
PDU
ADDRESS
REGISTER
VARIABLE
OTHERS
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 173
[h] 0x0AD
40174
model number
1
R
uint16
0…9999
[d] 160
[h] 0x0A0
40161
model suffix
1
R
char
Representation: ASCII character
[d] 162
[h] 0x0A2
40163
firmware version
2
R
uint32
0…999999
Representation: nn:nn:nn
[d] 165
[h] 0x0A5
40166
serial no
2
R
uint32
0…9999999
Representation: nnnnnnn
[d] 168
[h] 0x0A8
40169
password
1
R
uint16
0…9999
[d] 170
[h] 0x0AA
40171
tag-nr
2
R/W
uint32
0...9999999
Representation: nnnnnnn
