Fluiteco SD - Sludge Inlet-Outlet Connections

13
SLUDGE INLET-OUTLET CONNECTIONS
Inlet
Dimensions
Description
D
2”- 3” for
SD900
Sludge inlet MAX SLUDGE INLET PRESSURE 0,8 Bar
E
Ф 60,3 mm
SD200
Sludge dewatering water outlet
Ф 88,9 mm
SD400
Ф 101,3 mm
SD700
F
Dewatered sludge outlet
E
D
F
C
