Fluke 1653B User Manual

1
Introduction
The Fluke 1652C, 1653B, and 1654B are battery powered electrical installation testers
(the Tester). This manual applies to all three models. All figures show the 1653B.
In this manual, you will find the following topics:
• Safety Information
• General and Electrical Measurement Specifications
• Equipment Requirements
• Basic Maintenance
• Performance Tests
• Accuracy Tests
• Accessories and Replaceable Parts
For complete instructions on how to use the Tester, refer to the 1652C/1653B/1654B
Users Manual.
How to Contact Fluke
To contact Fluke, call one of the telephone numbers that follow:
• Technical Support USA: 1-800-99-FLUKE (1-800-993-5853)
• Calibration/Repair USA: 1-888-99-FLUKE (1-888-993-5853)
• Canada: 1-800-36-FLUKE (1-800-363-5853)
• Europe: +31 402-675-200
• Japan: +81-3-3434-0181
• Singapore: +65-738-5655
• Anywhere in the world: +1-425-446-5500
Or, visit Fluke's website at www.fluke.com
.
To register your product, visit http://register.fluke.com
.
To view, print, or download the latest manual supplement, visit
http://us.fluke.com/usen/support/manuals
.

Fluke 1653B Specifications

General

Insulation Test Voltage	50 V, 100 V, 250 V, 500 V, 1000 V
Loop and Line Resistance	0.01 Ω to 1999 Ω
Loop/Line Resistance	0.01 Ω to 1999 Ω
Frequency	45 Hz to 65 Hz
Resistance Measurement Range	0.01 Ω to 1999 Ω
Loop Impedance Measurement Range	0.01 Ω to 1999 Ω
Power Supply	6 x 1.5 V AA batteries
AC Voltage Range	500 V
DC Voltage Range	500 V
Insulation Resistance Range	0.01 MΩ to 1000 MΩ
Prospective Earth Fault Current (PEFC)	0 A to 20 kA
Prospective Short Circuit Current (PSC)	0 A to 20 kA
RCD Trip Time	300 ms
RCD Trip Current	10 mA to 1000 mA
Display	Digital
Safety Category	CAT III 500 V, CAT IV 300 V
RCD Trip Time Measurement Range	10 ms to 2000 ms
Dimensions	10 cm x 25 cm x 12.5 cm
Safety Standards	EN61557
