Fluke 1653B User Manual

Electrical Installation Tester
Specifications
7
RCD/FI Tests (
∆
T, I
∆
N)
RCD/FI Time RCD/FI Current
Limit Value Maximum Display Value Limit Value Maximum Display Value
20 18.1 0.5 0.43
30 27.1 0.6 0.52
40 36.1 0.7 0.61
50 45.1 0.8 0.7
60 54.1 0.9 0.79
70 63.1 1 0.88
80 72.1 2 1.78
90 81.1 3 2.68
100 90.1 4 3.58
200 180.1 5 4.48
300 271 6 5.38
400 361 7 6.28
500 451 8 7.18
600 541 9 8.08
700 631 10 8.98
800 721 20 17.98
900 811 30 26.8
1000 901 40 35.8
2000 1801 50 44.8
60 53.8
70 62.8
80 71.8
90 80.8
100 89.8
200 179.8
300 268
400 358
500 448

Fluke 1653B Specifications

General

Insulation Test Voltage	50 V, 100 V, 250 V, 500 V, 1000 V
Loop and Line Resistance	0.01 Ω to 1999 Ω
Loop/Line Resistance	0.01 Ω to 1999 Ω
Frequency	45 Hz to 65 Hz
Resistance Measurement Range	0.01 Ω to 1999 Ω
Loop Impedance Measurement Range	0.01 Ω to 1999 Ω
Power Supply	6 x 1.5 V AA batteries
AC Voltage Range	500 V
DC Voltage Range	500 V
Insulation Resistance Range	0.01 MΩ to 1000 MΩ
Prospective Earth Fault Current (PEFC)	0 A to 20 kA
Prospective Short Circuit Current (PSC)	0 A to 20 kA
RCD Trip Time	300 ms
RCD Trip Current	10 mA to 1000 mA
Display	Digital
Safety Category	CAT III 500 V, CAT IV 300 V
RCD Trip Time Measurement Range	10 ms to 2000 ms
Dimensions	10 cm x 25 cm x 12.5 cm
Safety Standards	EN61557
