1736/1738
Users Manual
4
WiFi and WiFi/BLE-to-USB Adapter
The USB adapter enables the wireless connectivity of the Logger:
•
Connection to the Fluke Connect
smartphone app for easy asset
management and data sharing.
•
Data transfer to Energy Analyze Plus PC software.
•
Remote control via Virtual Network Computing (VNC). See
page 58 for more information about VNC.
•
Display and store data of up to 2 modules of the Fluke FC 3000
series together with the instrument data into logging sessions
(requires WiFi/BLE or Bluetooth adapter feature, available with
firmware version 2.0).
To install the adapter in the Logger:
1.
Remove the Power Supply. See Figure 1.
2.
Unscrew the four screws.
3.
Remove the battery door.
4.
Remove the battery.
5.
Insert the WiFi/BLE adapter in the compartment with the serial
number visible.
6.
Connect the USB Bluetooth adapter on either the internal or
external USB port.
7.
Connect the WiFi/BLE adapter to the USB port by sliding it
gently to the right until the adapter snaps into the USB socket
of the Logger. About 3.5 mm (0.14 in) of the metal shield
should be visible.
If two dedicated USB adapters for WiFi and Bluetooth are
supplied, always connect the WiFi adapter to the internal USB
port.
8.
Insert the battery.
9.
Fasten the battery door.
Figure 1. Adapter Installation
WiFi
Bluetooth
2
1
3
4
5
6
WiFi
To Next Page
