Power Logger
Function Selection Buttons
35
The menu also provides the access to live values of Energy as:
•
Active Energy (Ep) Wh
•
Reactive Energy (E
Q
r) in varh
•
Apparent Energy (E
s
) in V Ah
To display a trend chart of the last 7 minutes of Power values:
1.
Push (Live-Trend).
2.
Use or the cursor keys to show the list of available
parameters.
3.
Push (Reset) to clear the graph and restart.
Note
In the user interface, the term Fundamental is sometimes
shortened to “Fund.” or “h01.”
Logger
– In Logger mode, you can:
•
Configure a new logging session
•
Review the data of an ongoing logging session in memory
•
Review the data of a completed logging session (as long as no
new session has been started)
Push and then (Logging Sessions) to review a logging
session.
Logging Session Setup
When no logging session is active, push to display the Setup
Summary screen for logging. This screen lists all logging parameters
such as:
•
Session name
•
Duration and optional recording date and time for start/stop
•
Interval of the average calculation
•
Demand interval (not available for load studies)
•
Energy costs (not available for load studies)
•
Description
To Next Page
