Power Logger
Navigation and User Interface
11
Navigation and User Interface
See Table 3 for a list of the front-panel controls and their functions.
See Table 4 for a list of the connectors and their functions.
Table 3. Front Panel
Item Control Description
Power on/off and status

Function selection
Memory/Setup selection

Cursor control
Selection control
Kensington Lock
Backlight on/off


Softkey selection
Touch screen display
1
2
3
4
5
6
7
8
9
