Fluke 1738 Calibration Manual

Logger/Monitor
Setup
11
Setup
Before you start the verification procedures or make calibration adjustments, refer to this section for the
equipment, system, and setup requirements.
Required Equipment
See Table 3 for a list of requirements for the verification tests and calibration adjustment of the Logger.
Table 3. Required Equipment
Equipment Model Notes
Used on:
Verification
Tests
Calibration
Adjustment
Calibrator 5522A 5520A is also supported
XX
Cable Assembly 3PHVL-1730
Voltage Test Lead
3-Phase+N
XX
173x AUX Input Calibration
Cable
[1]
NA
1732/1734/1736/1738 only
XX
173x Calibration Cables –
Voltage-to-Current Input Cable
Assembly
[1]
NA
1732/1734/3540 FC:
Qty. 3 required
1736/1738:
Qty. 4 required
XX
173x Verification Box
[1]
NA optional
X
USB cable type A-to-mini B
XX
DMM 8846A
for AUX Adapter
verification
X
Coil
5500A/COIL
Optional: 52120A
with Coils
for Flexi verification
X
Coil NA 5 turns
X
Banana-to-Pin Adapter
Pomona
Electronics 4690
for AUX Adapter
verification
X
[1] The 173x calibration cables and verification box are not available from Fluke. See Equipment Assembly for
information on how to make these items.

Fluke 1738 Specifications

General

Product type	Three phase power measurement logger
Cable lock slot type	Kensington
International Protection (IP) code	IP50
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Built-in display	Yes
Display diagonal	4.3 \
Touchscreen type	Resistive
Display resolution	480 x 272 pixels
Display technology	TFT
Efficiency	68.2 %
Battery life	4 h
Charging time	6 h
Battery voltage	3.7 V
Input frequency	50/60 Hz
Battery capacity	9.25 Wh
Power consumption (max)	50 VA
Battery life (power save mode)	5.5 h

Weight and Dimensions

Depth	55 mm
Width	198 mm
Height	167 mm
Weight	1100 g
Power adapter weight	400 g
Power supply dimensions (WxDxH)	130 x 45 x 130 mm
