Fluke 1738 Calibration Manual

1732/1734/1736/1738/3540 FC
Calibration Manual
4
Specifications
General Specifications
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.3-inch active matrix color TFT, 480 pixels x 272 pixels, resistive touch panel
Power/Charging/LED Indicator
Warranty
173x/3540 FC and Power Supply . . . . . . . . . . . . . . . . . . .2 years (battery not included)
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 year
Calibration Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 years
Dimensions
173x/3540 FC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19.8 cm x 16.7 cm x 5.5 cm (7.8 in x 6.6 in x 2.2 in)
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13.0 cm x 13.0 cm x 4.5 cm (5.1 in x 5.1 in x 1.8 in)
173x/3540 FC with power supply attached . . . . . . . . . . . . 19.8 cm x 16.7 cm x 9 cm (7.8 in x 6.6 in x 4.0 in)
Weight
173x/3540 FC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1 kg (2.5 lb)
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .400 g (0.9 lb)
Tamper Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Kensington lock
Environmental Specifications
Operating Temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . -10 °C to +50 °C (14 °F to 122 °F)
Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -20 C to +60 °C (-4 °F to +140 °F),
with battery: -20 °C to +50 °C (-4 °F to +122 °F)
Operating Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <10 °C (<50 °F) non condensing
10 °C to 30 °C (50 °F to 86 °F) ≤95 %
30 °C to 40 °C (86 °F to 104 °F) ≤75 %
40 °C to 50 °C (104 °F to 122 °F) ≤45 %
Operating Altitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2000 m (up to 4000 m derate to 1000 V CAT II/600 V CAT III/300 V CAT IV)
Storage Altitude. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 000 m
IP Rating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IEC 60529:IP50, in connected condition with protection caps in place
Vibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . MIL-T-28800E, Type 3, Class III, Style B
Safety
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IEC 61010-1: Pollution Degree 2
Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IEC 61010-2-033: CAT IV 600 V / CAT III 1000 V
Mains Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Overvoltage Category II, Pollution Degree 2
Voltage Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Overvoltage Category IV, Pollution Degree 2
Li-ion Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IEC 62133
Electromagnetic Compatibility (EMC)
International. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IEC 61326-1: Industrial
CISPR 11: Group 1, Class A
Group 1: Equipment has intentionally generated and/or uses conductively-
coupled radio frequency energy that is necessary for the internal function of the
equipment itself.
Class A: Equipment is suitable for use in all establishments other than domestic
and those directly connected to a low-voltage power supply network that
supplies buildings used for domestic purposes. There may be potential
difficulties in ensuring electromagnetic compatibility in other environments due to
conducted and radiated disturbances.
Emissions that exceed the levels required by CISPR 11 can occur when the
equipment is connected to a test object.
Korea (KCC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Class A Equipment (Industrial Broadcasting & Communication Equipment)
Class A: Equipment meets requirements for industrial electromagnetic wave
equipment and the seller or user should take notice of it. This equipment is
intended for use in business environments and not to be used in homes.
USA (FCC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 CFR 15 subpart B. This product is considered an exempt device per clause
15.103.

Fluke 1738 Specifications

General

Product type	Three phase power measurement logger
Cable lock slot type	Kensington
International Protection (IP) code	IP50
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Built-in display	Yes
Display diagonal	4.3 \
Touchscreen type	Resistive
Display resolution	480 x 272 pixels
Display technology	TFT
Efficiency	68.2 %
Battery life	4 h
Charging time	6 h
Battery voltage	3.7 V
Input frequency	50/60 Hz
Battery capacity	9.25 Wh
Power consumption (max)	50 VA
Battery life (power save mode)	5.5 h

Weight and Dimensions

Depth	55 mm
Width	198 mm
Height	167 mm
Weight	1100 g
Power adapter weight	400 g
Power supply dimensions (WxDxH)	130 x 45 x 130 mm
