Fluke 1738 Calibration Manual

Logger/Monitor
Setup
13
173x AUX Input Calibration Cable
See Table 5 and Figure 1 for instructions on how to make the calibration cable.
 Caution
Cable must be marked with “max. 30 V to earth.” Any voltage-, category-, or
current-ratings on safety plugs must be removed.
Table 5. 173x AUX Input Calibration Cable
Item Description Part Number/Info QTY

Binder: Series 620 - Male Cordset, 4-pole, 2 m Binder: 79 9241 020 04 1

Test Lead 0.75 mm² with 4 mm Banana Plug, stackable red 2

Test Lead 0.75 mm² with 4 mm Banana Plug, stackable black 2

Shrink tube Ø 5-6 mm, black, thin wall, 3:1 L = 30 mm 4

Shrink tube Ø 8-10 mm, transparent, thin wall, 2:1 L = 45 mm 2

Shrink tube Ø 10-12 mm, black, thin wall, adhesive, 3:1 L = 30135 1

Shrink tube Ø 12-14 mm, black, thin wall, 3:1 L = 110 mm 1

Fluke 1738 Specifications

General

Product type	Three phase power measurement logger
Cable lock slot type	Kensington
International Protection (IP) code	IP50
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Built-in display	Yes
Display diagonal	4.3 \
Touchscreen type	Resistive
Display resolution	480 x 272 pixels
Display technology	TFT
Efficiency	68.2 %
Battery life	4 h
Charging time	6 h
Battery voltage	3.7 V
Input frequency	50/60 Hz
Battery capacity	9.25 Wh
Power consumption (max)	50 VA
Battery life (power save mode)	5.5 h

Weight and Dimensions

Depth	55 mm
Width	198 mm
Height	167 mm
Weight	1100 g
Power adapter weight	400 g
Power supply dimensions (WxDxH)	130 x 45 x 130 mm
