Fluke 1738 User Manual

1736/1738
Users Manual
4
Table 1 is a list of symbols used on the Product or in this
manual.
Table 1. Symbols
Symbol Description Symbol Description

Consult user documentation.

Conforms to relevant South Korean EMC
standards.

WARNING. RISK OF DANGER.

Conforms to relevant Australian EMC standards.

WARNING. HAZARDOUS VOLTAGE. Risk of
electric shock.

Certified by CSA Group to North American safety
standards.

Earth

Conforms to European Union directives.

Battery
 Double Insulated

Measurement Category II is applicable to test and measuring circuits connected directly to utilization points (socket outlets
and similar points) of the low-voltage MAINS installation.

Measurement Category III is applicable to test and measuring circuits connected to the distribution part of the building’s low-
voltage MAINS installation.

Measurement Category IV is applicable to test and measuring circuits connected at the source of the building’s low-voltage
MAINS installation.

This product contains a Lithium-ion battery. Do not mix with the solid waste stream. Spent batteries should be disposed of by
a qualified recycler or hazardous materials handler per local regulations. Contact your authorized Fluke Service Center for
recycling information.

This product complies with the WEEE Directive marking requirements. The affixed label indicates that you must not discard
this electrical/electronic product in domestic household waste. Product Category: With reference to the equipment types in
the WEEE Directive Annex I, this product is classed as category 9 "Monitoring and Control Instrumentation" product. Do not
dispose of this product as unsorted municipal waste.

Fluke 1738 Specifications

General

Product type	Three phase power measurement logger
Cable lock slot type	Kensington
International Protection (IP) code	IP50
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Built-in display	Yes
Display diagonal	4.3 \
Touchscreen type	Resistive
Display resolution	480 x 272 pixels
Display technology	TFT
Efficiency	68.2 %
Battery life	4 h
Charging time	6 h
Battery voltage	3.7 V
Input frequency	50/60 Hz
Battery capacity	9.25 Wh
Power consumption (max)	50 VA
Battery life (power save mode)	5.5 h

Weight and Dimensions

Depth	55 mm
Width	198 mm
Height	167 mm
Weight	1100 g
Power adapter weight	400 g
Power supply dimensions (WxDxH)	130 x 45 x 130 mm
