Fluke 434-II/435-II/437-II
Service Manual
3-4
3.4 Final Assembly Parts
See Table below. In Chapter 6 – Disassembling the Analyzer, pictures are present giving
an impression on how the instrument is constructed.
Dedicated pictues with item numbers are scheduled for a future revision of this Service
Information.
Table 3-1. Final Assembly Parts and Kits
Part or Kit Ordering Code Consists of Following Parts Figure/Item nr
Case Set 43x-II 4161577 Front case (excl. lens/decal) 3-2/21
Inner lens (for double isolation) ---
Dustseal long (2x, around screen) ---
Dustseal short (2x, around screen) ---
Case seal (white) 3-2/27
Bottom case assy 3-1/3
Battery door 3-1/16
Adhesive foam (for battery door) ---
Quarter turn screw (2x) ---
Standup bracket 3-1/18
Quarter turn screw 948609 For battery door (1x) ---
Decal Set for Input
Sockets, Colored
4137197 Supplied with Analyzer as standard
accessory
---
Decal Set for Input
Sockets, Black &
White
4137201 Stuck on Analyzer at delivery ---
Li-ion Battery Pack BP290 (standard) 26 Wh, 10.8 V 3-1/17
Li-ion Battery Pack BP291 (optional) 52 Wh, 10.8 V 3-1/17
Lens/decal 434-II
4161589
--- ---
Lens/decal 435-II
4161592
--- ---
Lens/decal 437-II
4161605
--- ---
LCD assy Flk 43x-II
and Flk-190-II
3981844 LCD module
LCD fixation foam
Flat cable
3-2/23
Topholster 43x-II (Input
Cover)
4161610 Excluding decals 3-1/1
Mounting Material Set
43x-II
4161622
Selftapping screw black (2 pcs/instr,
to fix topholster)
3-1/2
Dowel (6 pcs/instr, to fix side strap +
hang strap)
3-1/5
Steel plate for Kensington lock (1
pce/instr)
3-1/9
Selftapping screw blank (6 pcs/instr,
to fix bottom case and battery door
detection)
3-1/4
3-1/8
Screw M3x6 (2 pcs/instr, to fix
bottom holster)
3-1/12
Square nut M3 (2 pcs/instr, to fix
bottom holster)
3-1/12
Selftapping screw blank (6 pcs/instr,
to fix Main PCA module to Front
3-2/22
