Calibration Adjustment
5.3 Starting The Calibration 5
5-5
• Operate to adjust each selected item Year, Month, and Day.
• Press
F5
to leave the SETUP DATE menu.
4. Select the calibration mode.
The Calibration Adjustment Procedure uses built-in calibration setups, that can be
accessed in the calibration mode.
To enter the calibration mode proceed as follows:
• Press and hold
, press and release
F5
, then release
.
The display shows the
MAINTENANCE screen (Calibration Adjustment mode).
The display shows the calibration step
Warming Up (CL 0200) , the calibration status
:IDLE (valid) or :IDLE (invalid) , and the soft key menu.
Continue as indicated in section 5.2.
You can leave the calibration mode without changing the calibration data by turning the
Analyzer off.
Explanation of screen messages and key functions.
When the Analyzer is in the calibration Mode, only the
F1
to
F5
soft keys, the
and the key can be operated, unless otherwise stated.
The calibration adjustment screen shows the actual calibration step (name and number)
and its status:
Cal Name (CL nnnn) :Status (...)
Cal Name
Name of the selected calibration step, e.g. Warming Up
(CL nnnn) Number of the calibration step
Status (...) can be:
IDLE (valid) After (re)entering this step, the calibration process is not started.
The calibration data of this step are valid. This means that the
last time this step was done, the calibration was successful. It
does not necessarily mean that the unit meets the specifications
related to this step!
IDLE (invalid) After (re)entering this step, the calibration process is not started.
The calibration data are invalid. This means that the last time this
step was done, the calibration was not successful. Most probably
the unit will not meet the specifications if the actual calibration
data are saved.
BUSY aaa% bbb% Calibration adjustment step in progress; progress % for Input A
and Input B. During Warming Up the elapsed time is shown.
READY Calibration adjustment step finished.
