Fluke 19xC - Dual Input Oscilloscope

Fluke 19xC-2x5C
Users Manual
114
Dual Input Oscilloscope
Isolated Inputs A and B (Vertical)
Bandwidth, DC Coupled
FLUKE 199C, 225C .............................200 MHz (-3 dB)
FLUKE 196C, 215C .............................100 MHz (-3 dB)
FLUKE 192C..........................................60 MHz (-3 dB)
Lower Frequency Limit, AC Coupled
with 10:1 probe .........................................<2 Hz (-3 dB)
direct (1:1).................................................<5 Hz (-3 dB)
Rise Time
FLUKE 199C, 225C ............................................. 1.7 ns
FLUKE 196C, 215C ............................................. 3.5 ns
FLUKE 192C........................................................ 5.8 ns
Analog Bandwidth Limiters ................20 MHz and 10 kHz
Input Coupling.......................................................AC, DC
Polarity....................................................Normal, Inverted
Sensitivity Ranges
with 10:1 probe ..............................20 mV to 1000 V/div
direct (1:1)..........................................2 mV to 100 V/div
Dynamic Range .................................> ±8 div (< 10 MHz)
.....................................................> ±4 div (> 10 MHz)
Trace Positioning Range ............................... ±4 divisions
Input Impedance on BNC
DC Coupled ....................... 1 MΩ (±1 %)//15 pF (±2 pF)
Max. Input Voltage
with 10:1 probe.................600 V CAT III; 1000 V CAT II
direct (1:1) ................................................ 300 V CAT III
(For detailed specifications, see “Safety”)
Vertical Accuracy ......................±(1.5 % + 0.04 range/div)
2 mV/div: ....±(2.5 % + 0.08 range/div)
For voltage measurements with 10:1 probe, add probe
accuracy, see section ‘10:1 Probe’ on page
127.
Digitizer Resolution ..................... 8 bits, separate digitizer
for each input
Horizontal
Maximum Time Base Speed:
FLUKE 196C, 199C, 215C, 225C...................... 5 ns/div
FLUKE 192C ................................................... 10 ns/div
Minimum Time Base Speed (Scope Record) ..... 2 min/div
Real Time Sampling Rate (for both inputs simultaneously)
FLUKE199C, 225C:
5 ns to 5 μs /div ....................................up to 2.5 GS/s
10 μs to 120 s/div ...........................................20 MS/s
FLUKE 196C, 215C:
5 ns to 5 μs /div .......................................up to 1 GS/s
10 μs to 120 s/div ...........................................20 MS/s
FLUKE 192C:
10 ns to 5 μs /div .................................up to 500 MS/s
10 μs to 120 s/div ...........................................20 MS/s
Record Length
