Miscellaneous
Display
View Area ........................ 115 x 86 mm (4.5 x 3.4 inches)
Backlight ..................... Cold Cathode Fluorescent (CCFL)
Temperature compensated
Brightness................................ Power Adapter: 80 cd/m
2
Batteries: 50 cd/m
2
Power
Rechargeable NiMH Batteries:
Operating Time .................................................. 4 hours
Charging Time ................................................... 4 hours
Allowable ambient
temperature during charging: ..... 0 to 40 °C (32 to 104 °F)
Auto power down
time (battery saving): ............. 5 min, 30 min or disabled
Battery Charger / Power Adapter BC190:
• BC190/801 European line plug 230 V ±10 %
• BC190/813 North American line plug 120 V ±10 %
• BC190/804 United Kingdom line plug 230 V ±10 %
• BC190/806 Japanese line plug 100 V ±10 %
• BC190/807 Australian line plug 230 V ±10 %
• BC190/808 Universal switchable adapter 115 V ±10 %
or 230 V ±10 %, with plug EN60320-2.2G
Line Frequency ........................................... 50 and 60 Hz
Probe Calibration
Manual pulse adjustment and automatic DC adjustment
with probe check.
Generator Output ...................................... 3 Vpp / 500 Hz
square wave
Memory
Number of Scope Memories .........................................15
Each memory can contain two waveforms plus
corresponding setups
Number of Recorder Memories.......................................2
Each memory can contain:
• a dual input TrendPlot
(2 x 9000 points per input)
• a dual input Scope Record
(2 x 27000 points per input)
• 100 dual input Scope screens
Mechanical
Size.....................64 x 169 x 256 mm (2.5 x 6.6 x 10.1 in)
Weight.......................................................... 2 kg (4.4 lbs)
including battery
