Fluke 353 User Manual

353/355
Users Manual
16
Voltage Measurement (355 only) 10 Hz to 100 Hz
600 and 1000 V ranges have 10 % over range to 660 and 1100 V respectively.
Range Resolution Accuracy
Trigger Level for Hz
Filter OFF
Trigger Level for Hz
Filter ON
4 V 1 mV 1 % rdg + 10 digits 0.050 V 0.050 V
40 V 10 mV 1 % rdg + 5 digits 0.25 V 0.25 V
400 V 100 mV 1 % rdg + 5 digits 6 V 6 V
600 V AC RMS 1 V 1 % rdg + 5 digits 6 V 6 V
1000 V DC 1 V 1 % rdg + 5 digits N/A N/A
Voltage Measurement (355 only) 100.1 Hz to 1 kHz
600 and 1000 V ranges have 10 % over range to 660 and 1100 V
Range Resolution Accuracy
4 V 1 mV 3 % rdg + 10 digits
40 V 10 mV 3 % rdg + 5 digits
400 V 100 mV 3 % rdg + 5 digits
600 V AC RMS 1 V 3 % rdg + 5 digits
Ohms Measurement (355 only)
Range Resolution Accuracy
400 Ω 0.1 Ω 1.5 % + 5 digits
4 k Ω 1 Ω 1.5 % + 5 digits
40 k Ω 10 Ω 1.5 % + 5 digits
400 k Ω 100 Ω 1.5 % + 5 digits

Fluke 353 Specifications

General

DC voltage	1000 V
Low pass filter	Yes
DC current (max)	2000 A
Measuring category	CAT III 1000V, CAT IV 600V
AC current maximum resolution (probe)	1 A
Battery type	AA
Number of batteries supported	6
Certification	IEC 61010-2-032, CE, RoHS, EMI, RFI, EMC, IP42
Product color	Black, Red, Yellow
Operating altitude	0 - 2000 m
Non-operating altitude	0 - 10000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Depth	52 mm
Width	98 mm
Height	300 mm
Weight	814 g
