List of Replaceable Parts
Parts Lists
8
8-5
Table 8-2. Final Assembly (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
H437 SCREW,PH,P,LOCK,SS,6-32,.750 376822 2
H439 SCREW,TH,P,LOCK,STL,8-32,.250 853622 4
H443 SCREW,PH,P,LOCK,STL,6-32,.625 152181 4
H505 NUT,HEX,BR,1/4-28 110619 1
H506 WASHER,LOCK,INTRNL,STL,.267ID 110817 1
H513 WASHER,FLAT,SS,.119,.187,.010 853296 2
H545 NUT,EXT LOCK,STL,6-32,.344OD 152819 1
L3-6 CORE,TOROID,FERRITE,.047X.138X 321182 4
MP1 TRANSISTOR SET 842880 2
MP2 LABEL, CE MARK, BLACK 600707 1
MP3 TRANSISTOR SET 842992 2
MP5 HEATSINK, HIGH VOLTAGE 843115 4
MP9 DECAL,HEATSINK 850230 4
MP15 ASSY, THERMISTOR 843032 1
MP16 CABLE ACCESS,TIE,4.00L,.10W,.7 172080 24
MP39 HEAT DIS,ACC,AL FOIL,TO-3 838169 8
MP47 SLEEV,POLYOL,SHRINK,.187-.093I 113852 1
MP302 HANDLE,INSTRUMENT, GRAY #7 886341 4
MP304 INSULATOR,BINDING POST,FRONT,G 885459 4
MP306 REAR INSULATOR GRAY #3 894183 4
MP308 BINDING POST-RED 886382 2
MP309 BINDING POST-BLACK 886379 2
MP310 DECAL,FRONT 886317 1
MP311 NAMEPLATE,TITTLE 850164 1
MP312 POWER BUTTON, ON/OFF 775338 1
MP405 DECAL,WARNING 850243 2
MP410 SIDE EXTRUSION 886288 2
MP412 INSERT EXTRUSION 886283 2
MP414 ADHESIVE SIDE TRIM 698316 2
MP416 BOTTOM FOOT, MOLDED, GRAY #7 868786 4
MP501 DECAL, CSA 864470 1
MP510 LINE FILTER ASSEMBLY 850172 1
MP511 FAN ASSEMBLY 843029 1
MP512 BINDING HEAD, PLATED 102889 1
MP513 BINDING POST, STUD, PLATED 102707 1
MP514 LABEL,VINYL,1.500,.312 844712 1
MP516 FAN GUARD AND AIR FILTER 886416 1
MP600 FRONT PANEL 886408 1
MP601 REAR PANEL 886411 1
MP602 HOUSING, AIR FILTER 886416 1
MP603 COVER, TOP 660951 1
MP604 COVER, BOTTOM 660958 1
MP605 DIVIDER, HIGH VOLTAGE MODULE 860176 1
MP606 TOP INSULATOR ASSY, HIGH VOLTAGE MODULE 860192 1
MP607 BOTTOM INSULATOR ASSY, HIGH VOLTAGE MODULE 860197 1
