Fluke 5725A - A2 Current Amplifier PCA

List of Replaceable Parts
Parts Lists
8
8-17
Table 8-4. A2 Current Amplifier PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C201,C202,C207,
C208,C211,C212,
C226,C227,C236
CAP,AL,22UF,+-20%,35V 817056
817056
817056
9
C203,C204,C216,
C217,C238-240
CAP,POLYES,0.1UF,+-10%,50V 649913
649913
7
C205,C206 CAP,POLYES,0.001UF,+-10%,50V 720938 2
C210,C214,C215,
C234
CAP,POLYES,0.47UF,+-10%,50V
697409
697409
4
C213 CAP,CER,22PF,+-2%,50V,C0G 714832 1
C218-221 CAP,AL,50000UF,+100-10%,20V,LO 830539 4
C222,C223 CAP,AL,470UF,+-20%,35V,SOLV PR 756700 2
C224,C225 CAP,AL,10UF,+-20%,63V,SOLV PRO 816843 2
C228 CAP,CER,100PF,+-5%,50V,C0G 831495 1
C230 CAP,CER,47PF,+-2%,100V,C0G 832295 1
C233 CAP,TA,2.2UF,+-20%,16V 706804 1
C235 CAP,POLYES,1UF,+-10%,100V 447847 1
C237 CAP,CER,39PF,+-2%,50V,C0G 714840 1
CR201-204,
CR207,CR220,
CR221
*
*
*
DIODE,SI,BV=75V,IO=150MA,500MW 203323
203323
203323
7
CR205 * DIODE,SI,N-JFET,CURRENT REG,IF 334839 1
CR206 DIODE,SI,RECT,BRIDGE,BV=50V,IO 886945 1
CR208-219,
CR222
DIODE,SI,400 PIV,1 AMP 831586
831586
13
E255 TERM,FASTON,TAB,.110,SOLDER 512889 1
F201,F202 FUSE,.25X1.25,20A,32V,FAST 518860 2
H16 WASHER,FLAT,STL,.170,.375,.031 110288 1
H25 RIVET,POP,DOME,AL,.125,.316 807347 4
H201 LABEL,C-MOS INSTRUCTION 464016 1
H207 RIVET,S-TUB,OVAL,AL,.087,.250 838482 2
H209 SCREW,PH,P,LOCK,STL,8-32,.625 114983 1
H210 SCREW,PH,P,SEMS,STL,6-32,.375 177022 6
H216 SCREW,PH,P,LOCK,MAG SS,6-32,.2 772236 8
H230 NUT,BROACH,STL,6-32 393785 2
H232 SCREW,PH,P,SS,10-32,.250 855184 8
J201 CONN,MATE-N-LOK,HEADER,8 PIN 570515 1
J202 CONN,DIN41612,TYPE 1/2R,32 PIN 836874 1
J204 HEADER,1 ROW,.100CTR,2 PIN 643916 1
J205 HEADER,1 ROW,.100CTR,2 PIN 602698 1
J222 CONN,MATE-N-LOK,HEADER,4 PIN 512269 1
J252 CONN,COAX,SMB(M),PWB 352450 1
K201,K205-209 RELAY,ARMATURE,2 FORM C,5V 733063 6
K202-204 RELAY,ARMATURE,2 FORM A,5VDC 830547 3
L201 CHOKE, 3 TURN 452888 1
