Fluke 5725A - A4 Power Supply PCA

List of Replaceable Parts
Parts Lists
8
8-25
Table 8-6. A4 Power Supply PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C301,C302,C321,
C322
CAP,AL,220UF,+-20%,350V 854075
854075
4
C303,C304,C308,
C317-319,C352,
C355,C358,C360,
C362
CAP,POLYES,0.1UF,+-10%,50V 649913
649913
649913
649913
11
C305,C306 CAP,AL,0.47UF,+-20%,50V 769695 2
C307 CAP,POLYES,0.047UF,+-10%,50V 820548 1
C309 CAP,CER,82PF,+-2%,50V,C0G 714857 1
C310,C311,C313,
C320
CAP,CER,0.04UF,+-20%,3000V,Y5V 851725
851725
4
C312,C363 CAP,CER,33PF,+-5%,50V,C0G 714543 2
C314 CAP,POLYES,0.47UF,+-10%,50V 697409 1
C315,C316 CAP,POLYES,0.01UF,+-10%,50V 715037 2
C350 CAP,AL,10000UF,+-20%,25V 816819 1
C351,C354,C357,
C359,C361
CAP,AL,10UF,+-20%,63V,SOLV PRO 816843
816843
5
C353,C356,C369 CAP,AL,3300UF,+-20%,50V 782458 3
C364-368 CAP,POLYES,0.33UF,+-10%,50V 715284 5
CR301-304,
CR310-313
*
*
DIODE,SI,1K PIV,1.0 AMP 707075
707075
8
CR305-309,
CR316,CR321
DIODE,SI,BV=75V,IO=150MA,500MW 203323
203323
7
CR314,CR315,
CR319,CR320,
CR322-325,
CR350, CR352-
354,CR356-363
DIODE,SI,400 PIV,1 AMP
831586
831586
831586
831586
831586
20
CR317,CR318 LED,RED,T1,40 MCD 845412 2
CR351,CR355 DIODE,SI,RECT,BRIDGE,BV=50V,IO 586115 2
E301 HEADER,1 ROW,.100CTR,4 PIN 417329 1
E302 SURGE PROTECTOR,630V,+-15% 853767 1
F301,F302 FUSE,.406X1.375,2A,600V,FAST 747600 2
H301 RIVET,S-TUB,OVAL,AL,.087,.250 838482 1
H302 RIVET,S-TUB,OVAL,AL,.087,.250 838482 1
H303- RIVET,POP,DOME,AL,.125,.316 807347 4
H307 RIVET,S-TUB,OVAL,STL,.118,.156 103424 4
J301,J303 CONN,MATE-N-LOK,HEADER,8 PIN 570515 2
J302,J350 HEADER,1 ROW,.156CTR,8 PIN 385435 2
J351 CONN,DIN41612,TYPE 1/2R,32 PIN 836874 1
MP28 * INSULATOR,PWR SUPPY HIGH VOLT 843102 1
MP81 CLAMP,PWB MOUNTING 823039 1
MP82 CLAMP,PWB MOUNTING 842948 1
MP301 HLDR,FUSE,13/32,PWB MT 516880 4
