Fluke 5725A - Auxiliary Amplifier Specifications

5725A
Instruction Manual
1-30
1-19. Auxiliary Amplifier Specifications
For complete specifications, see the 5205A and 5220A Operators Manuals.
5205A (220V - 1100 V ac, 0 V - 1100 V dc)
Overshoot: < 10 %
Distortion (bandwidth 10 Hz - 1 MHz):
10 Hz - 20 kHz
20 kHz - 50 kHz
50 kHz - 100 kHz
0.07 %
0.2 %
0.25 %
Frequency
(Hz)
90 Day Accuracy
at 23° ±5 °C
± (% output + % range)
Temperature Coefficient for
0°-18 °C and 28°-50 °C
± (ppm output + ppm range)/ °C
00 dc
010 - 40
040 - 20 k
20 k - 50 k
50 k - 100 k
0.05 + 0.005
0.15 + 0.005
0.04 + 0.004
0.08 + 0.006
00.1 + 0.01
15 + 3
45 + 3
15 + 3
50 + 10
70 + 20
5220A (AC Current, 180-day specifications):
Accuracy:
20 Hz - 1 kHz
1 kHz - 5 kHz
0.07% + 1 mA
(0.07% + 1mA) x frequency in kHz
Temperature Coefficient (0° - 18 °C and 28° - 50 °C): (0.003 % + 100 µA)/°C
Distortion (bandwidth 300 kHz):
20 Hz - 1 kHz
1 kHz - 5 kHz
0.1% + 1 mA
(0.1% + 1 mA) x frequency in kHz
Note: 5700A/5720A combined with 5220A is not specified for inductive loads.
