Fluke 5725A - A5 Digital PCA

List of Replaceable Parts
Parts Lists
8
8-29
Table 8-7. A5 Digital PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C501,C503-511,
C516,C518,C519,
C521
CAP,POLYES,0.1UF,+-10%,50V 649913
649913
649913
14
C502,C520 CAP,AL,22UF,+-20%,35V 817056 2
C512,C513 CAP,CER,15PF,+-20%,50V,C0G 697524 2
C514,C517 CAP,POLYES,0.33UF,+-10%,50V 715284 2
C515 CAP,TA,10UF,+-20%,35V 816512 1
C522-530 CAP,CER,470PF,+-5%,50V,C0G 830430 9
C531 CAP,CER,100PF,+-5%,50V,C0G 831495 1
CR501,CR504,
CR505
LED,GREEN,LIGHT BAR,5.0 MCD 845136
845136
3
CR502,CR506,
CR507
LED,RED,LIGHT BAR,6.0 MCD 534834
534834
3
CR508,CR509 * DIODE,SI,SCHOTTKY,40V,DO-34 313247 2
E501 HEADER,1 ROW,.100CTR,4 PIN 417329 1
J501 SOCKET,IC,0.070 CTR,64 PIN 783688 1
J502 HEADER,2 ROW,.100CTR,RT ANG,34 836551 1
J504 SOCKET,IC,28 PIN 448217 1
J506-509 SOCKET,IC,8 PIN 478016 4
J512,J515 SOCKET,IC,24 PIN 376236 2
L501 CHOKE, 3 TURN 452888 1
MP501 PAD, ADHESIVE 735365 1
MP502 SLEEVING 142554 1
MP815 CABLE, INTERCONNECT - FRONT PA 843123 1
R501 RES,MF,1M,+-1%,0.125W,100PPM 268797 1
R502,R509 RES,CF,1K,+-5%,0.25W 343426 2
R503-507 RES,CF,47K,+-5%,0.25W 348896 5
R508 RES,MF,11.5,+-1%,0.125W,100PPM 339796 1
R510 RES,CF,10K,+-5%,0.25W 348839 1
SW502 SWITCH,PUSHBUTTON,SPST,MOMENTA 782656 1
TP501-510 JUMPER,WIRE,NONINSUL,0.200CTR 816090 10
U501,U510 * IC,CMOS,OCTAL D TRANSPARENT LA 743294 2
U502 * IC,CMOS,HEX INVERTERS 799924 1
U503 * IC,CMOS,OCTL LINE DRVR W/3-ST 741892 1
U504 * IC, 2K X 8 STAT RAM 647222 1
U505 * IC,CMOS,QUAD INPUT NOR GATE 811158 1
U506 * IC,CMOS,14 STAGE BINARY COUNTE 807701 1
U507 * IC,CMOS,8-BIT MPU,2.0 MHZ,256 876326 1
U508 * IC,VOLT SUPERVISOR,4.55V SENSE 780577 1
U509 * IC,CMOS,DUAL MONOSTABLE MULTIB 454017 1
U511,U514 * IC,CMOS,QUAD 2 INPUT NAND GATE 707323 2
U512 IC, NMOS, 2K X 8 EEPROM, 350 N 811075 1
U513 * IL,CMOS,QUAD 2 INPUT AND GATE 741801 1
U515 * EPROM,PROGRAMED 27128A-150 U51 860148 1
Y501 CRYSTAL,4.9152 MHZ,+/- 0.005%, 800367 1
Z501 RES,CERM,DIP,16 PIN,15 RES,10K 355305 1
Z502 RES,CERM,DIP,16 PIN,8 RES,24,+ 806406 1
