Fluke 5725A - A12 Transformer Enclosure Assembly

List of Replaceable Parts
Parts Lists
8
8-35
Table 8-9. A12 Transformer Enclosure Assembly
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
H1 SCREW,FHU,P,LOCK,SS,6-32,.250 320093 4
H5 SCREW,PH,P,LOCK,MAG SS,6-32,.2 772236 20
H39 SCREW,PH,P,LOCK,STL,6-32,.625 152181 2
H41 SCREW,PH,P,LOCK,SS,4-40,.187 149567 2
H43 SCREW,PH,P,LOCK,SS,6-32,.500 320051 1
H44 SCREW,PH,P,LOCK,STL,6-32,.750 114223 5
H49 WASHER,FLAT,STL,.149,.375,.031 110270 2
H51 SCREW,HH,H,LOCK,STL,10-32,.375 854794 2
H53 SCREW,PH,P,LOCK,STL,6-32,.187 381087 4
H61 SCREW,HH,H,STL,1/4-20,4.00 845078 4
H65 WASHER,LOCK,SPLIT,STL,.255,.49 111518 4
H69 WASHER,FLAT,STL,.260,.375,.032 312538 4
H73 SCREW,PH,P,LOCK,STL,6-32,.375 152165 2
H75 SCREW,PH,P,LOCK,STL,10-32,.625 114066 2
MP1 BUSHING,SNAP-IN,NYL,.500 ID 102780 3
MP4 CABLE ACC,CLAMP,.687 DIA,SCREW 853775 2
MP12 MACHINED SHEET METAL XFORMER A 860143 1
MP13 SHEET METAL XFORMER ASSY 850300 1
MP18 SUPPORT,TRANSFORMER MTG 842919 2
MP403 CABLE, POWER SWITCH 881847 1
MP802 SHIELD, TRANSFORMER, BASE 842898 1
MP803 SHIELD,PWR,TRANSFORMER,COVER 850185 1
MP804 CUSHION,TRANSFORMER MTG. 842914 2
P2,P604 HOUSING,1 ROW,0.156 CTR,LOCK,1 446716 2
P403 HOUSING,1 ROW,0.156 CTR,LOCK,5 831164 1
T1 LOW FREQ 823336 1
T2 XFORMER MED FREQUENCY 823344 1
T3 HIGH FREQ 823351 1
T101 POWER TRANSFORMER 823369 1
TB001 TERM STRIP,BULKHEAD,.375CTR,2 276519 1
W4 HARNESS, CURRENT, FRONT 842997 1
W5 HARNESS,CURRENT,REAR 843003 1
W17 CABLE, TRANSFORMER BLACK 850222 1
W18 CABLE, TRANSFORMER WHITE 850227 1
