Fluke 5725A - Page 166

5725A
Instruction Manual
8-26
Table 8-6. A4 Power Supply PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
MP310 AIDE,PCB PULL 541730 2
MP350 HEAT DIS,VERT,1.13X1.90X0.95,T 830844 3
MP398 PAD, ADHESIVE 735365 2
P301 JUMPER,REC,2 POS,.100CTR,.025 530253 1
Q301,Q302,Q317,
Q318
*
*
HEAT SINK ASSY 665536
665536
4
Q303-305,Q315,
Q321,Q322
*
*
TRANSISTOR,SI,NPN,HI-VOLTAGE,T 722934
722934
6
Q306,Q307,Q311,
Q316,Q323,Q324
*
*
TRANSISTOR,SI,PNP,SM SIG,SELEC
602961
602961
6
Q308 * TRANSISTOR,SI,PNP,40V,0.35W,TO 698233 1
Q309 * TRANS,SI,N-JFET,REMOTE CUTOFF, 707968 1
Q310,Q314 * TRANSISTOR,SI,NPN,SMALL SIGNAL 698225 2
Q312,Q313,Q319,
Q320
*
*
HEAT SINK ASSY 66554
66554
4
Q350,Q351 * TRANSISTOR,SI,BV= 40V, 40W,TO- 418459 2
R301,R302,R342,
R343
RES,CF,470K,+-5%,0.25W
342634
342634
4
R303,R308,R335,
R339
RES,MOX,33K,+-5%,1W 644952
644952
4
R304,R305,R340,
R341
RES,CF,33K,+-5%,0.25W 348888
348888
4
R306,R332,R349 RES,MF,10K,+-1%,0.125W,100PPM 168260 3
R307,R309,R356 RES,CF,6.8K,+-5%,0.25W 368761 3
R310,R311,R346,
R347
RES,CF,1.5M,+-5%,0.25W 349001
349001
4
R312,R317,R330,
R331,R353 R357-
360
RES,CF,100,+-5%,0.25W
348771
348771
348771
9
R313,R329 RES,MF,0.39,+-5%,2W 219386 2
R314,R315,R336,
R337
RES,CF,15K,+-5%,0.5W 687795
687795
4
R316,R324,R338 RES,CF,100K,+-5%,0.25W 348920 3
R318 RES,MF,86.6K,+-1%,0.125W,25PPM 257402 1
R319 RES,MF,28.7K,+-1%,0.125W,100PP 235176 1
R320,R325,R328,
R348,R354
RES,CF,10K,+-5%,0.25W
348839
348839
5
R321 RES,MF,40.2K,+-1%,0.125W,100PP 235333 1
R322,R333 RES,MF,499,+-1%,,0.125W,100PM 168211 2
R323 RES,MF,6.19K,+-1%,0.125W,100PP 283911 1
R326 RES,MF,604,+-1%,0.125W,100PPM 320309 1
R327 RES,MF,60.4K,+-1%,0.125W,100PP 291419 1
R334 RES,CF,2K,+-5%,0.25W 441469 1
R344,R345 RES,CF,240K,+-5%,0.25W 442459 2
R350,R352 RES,MF,20K,+-1%,0.125W,100PPM 291872 2
