List of Replaceable Parts
Parts Lists
8
8-27
Table 8-6. A4 Power Supply PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
R351 RES,CF,1K,+-5%,0.25W 343426 1
R355 RES,CF,4.7K,+-5%,0.25W 348821 1
R361,R362 RES,CF,4.7,+-5%,0.25W 441584 2
RT350 THERMISTOR,DISC,O.12,25C 838144 1
RT351-354 THERMISTOR,DISC,0.81,25C 838136 4
SW301,SW302 SWITCH,PUSHBUTTON,SPST,MOMENTA 782656 2
TP301-307,TP350-
355,TP357-360
JUMPER,WIRE,NONINSUL,0.200CTR
816090
816090
17
U301 IC,COMPARATOR,DUAL,LO-PWR,8 PI 478354 1
U302 IC,CMOS,DUAL D F/F,+EDG TRG W/ 536433 1
U350,U353 IC,VOLT REG,FIXED,+5 VOLTS,1.5 647073 2
U351 IC,VOLT REG,FIXED 15VOLTS,1.5A 772830 1
U352 IC,VOLT REG,FIXED,-15 VOLTS,1. 413179 1
U354 IC,OP AMP,GENERAL PURPOSE,8 PI 478107 1
VR301,VR302,
VR304,VR305
ZENER,UNCOMP,15.0V,5%,8.5MA,0. 266601
266601
4
VR303 ZENER,UNCOMP,16.0V,5%,7.8MA,0. 325837 1
VR306,VR307 ZENER,UNCOMP,3.9V,10%,20.0MA,0 113316 2
VR351 ZENER,UNCOMP,3.9V,5%,320.0MA,5 386995 1
VR352 ZENER,UNCOMP,24.0V,5%,5.2MA,0. 267807 1
W8 HARNESS, HIGH VOLTAGE SUPPLY 843016 1
