Fluke 5725A - Page 158

5725A
Instruction Manual
8-18
Table 8-4. A2 Current Amplifier PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
MP2 INSULATOR, CURRENT 850151 1
MP28 INSULATOR, CURRENT 850156 1
MP38 BUMPER, HI-TEMP, SILICONE 16018701 1
MP81 CLAMP,PWB MOUNTING 823039 1
MP82 CLAMP,PWB MOUNTING 842948 1
MP203 HEAT DIS,PRESS ON,TO-5 418384 2
MP205 HEAT DIS,VERT,.83,.50,.395,TO- 800144 1
MP206 HEAT DIS,ACC,AL FOIL,TO-3 838169 2
MP211 FUSE CLIP PCB 756460 4
MP215 SOCKET,SINGLE,PWB,FOR .042-.04 544056 4
MP225 AIDE,PCB PULL 541730 2
MP256 INSUL PT,TRANSISTOR MOUNT,DAP, 152207 2
MP812 HEATSINK, CURRENT 843110 1
MP816 HEATSINK, RECTIFIER 850169 1
Q201 * TRANSISTOR,SI,PNP,40V,0.35W,TO 698233 1
Q202 * TRANSISTOR,SI,NPN,SMALL SIGNAL 698225 1
Q203 * TRANSISTOR,SI,PNP,SMALL SIGNAL 402586 1
Q204 * TRANSISTOR,SI,NPN,SMALL SIGNAL 346916 1
Q205 * TRANSISTOR,SI,BV=100V,50W,TO-2 454041 1
Q206 * TRANSISTOR,SI,BV=100V,40W,TO-2 454033 1
Q207 * TRANSISTOR,SI,BV=60V,200W,TO-3 483222 1
Q208 * TRANSISTOR,SI,BV=60V,200W,TO-3 483230 1
Q211 * TRANSISTOR,SI,N-JFET,TO-92 832154 1
Q212,Q213 * TRANSISTOR,SI,N-JFET,REMOTE CU 697987 2
Q214,Q215 * TRANSISTOR,SI,PNP,80V,0.625W,T 816272 2
Q216 * TRANSISTOR,SI,N-MOS,350MW,TO-9 783449 1
R201,R202 RESISTOR .086 OHM 1% 4 TERM 10 490771 2
R203,R204 RES,MF,43.2,+-1%,0.5W,100PPM 601823 2
R205 RES,MF,1K,+-1%,0.125W,100PPM 168229 1
R206,R234,R274,
R275
RES,MF,31.6K,+-1%,0.125W,100PP 261610
261610
4
R207,R222,R232,
R235,R239-241
RES,MF,39.2K,+-0.1%,0.125W,25P
344507
344507
7
R209 RES,MF,90.9,+-0.1%,0.5W,25PPM 423947 1
R211,R251,R252 RES,MF,3.92K,+-0.1%,.125W,25PP 844662 3
R212 RES,MF,2K,+-0.1%,0.125W,25PPM 340174 1
R213,R214,R217,
R218,R231,R271
RES,CF,330,+-5%,0.25W 368720
368720
6
R215,R216,R249,
R250
RES,MF,3.48K,+-1%,0.125W,100PP 260687
260687
4
R219,R220 RES,CC,5.1,+-5%,1W 219071 2
R221,R225,R226 RES,CC,51,+-5%,0.5W 687829 3
R223,R224,R227,
R228
RES,CF,1,+-5%,0.25W 357665
357665
4
