List of Replaceable Parts
Parts Lists
8
8-19
Table 8-4. A2 Current Amplifier PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
R233,R237,R238,
R273
RES,MF,2K,+-1%,0.125W,100PPM 235226
235226
4
R243,R244 RES,CF,100K,+-5%,0.25W 348920 2
R247,R248 RES,MF,232,+-1%,0.125W,100PPM 289975 2
R253,R277,R282,
R283,R285,R286
RES,MF,10K,+-1%,0.125W,100PPM
168260
168260
6
R255,R267,R268 RES,CF,470K,+-5%,0.25W 342634 3
R256-259 RES,MF,1M,+-1%,0.125W,100PPM 268797 4
R260 RES,LF,5.1,+-5%,0.5W 687779 1
R261,R263, R290-
295
RES,CF,4.7K,+-5%,0.25W 348821
348821
8
R262 RES,CF,150,+-5%,0.25W 343442 1
R264 RES,CF,1K,+-5%,0.25W 343426 1
R272 SHUNT ASSY 842877 1
R276 RES,MF,9.09K,+-1%,0.125W,100PP 221663 1
R281 RES,MF,24.9K,+-1%,0.125W,100PP 291369 1
R284 RES,MF,44.2K,+-1%,0.125W,25PPM 706317 1
RT201,RT202 THERMISTOR,DISC,4.85,25C 838102 2
TP201-
205,TP207-215
JUMPER,WIRE,NONINSUL,0.200CTR
816090
816090
17
U201 * IC,OP AMP,PRECISION,LOW NOISE 866637 1
U202 * IC,OP AMP,PRECISION,LOW NOISE 816744 1
U203 * IC,OP AMP,CURRENT AMP,TO-99 CA 260422 1
U204 * IC,OP AMP,DUAL,PRECISION MATCH 782375 1
U205 * IC,VOLT REG,ADJ,1.2 TO 37 V,1. 460410 1
U206 * IC,VOLT REG,ADJ,NEG,-1.2VT0-37v, 1.5A 772996 1
U207 * IC,COMPARATOR,DUAL,LO-PWR,8 PI 478354 1
U208 * IC,OP AMP,PRECISION,LOW NOISE 782920 1
U209 * IC,BIMOS,8 CHNL HI-VOLT DRVR W 782912 1
U210 * IC,COMPARATOR,QUAD,14 PIN DIP 387233 1
U211 * IC,OP AMP,QUAD,JFET INPUT,14 P 483438 1
VR201,VR202 * ZENER,UNCOMP,6.8V,5%,20.0MA,0. 260695 2
W6 HARNESS, MFC CURRENT 843008 1
w206 ASSY, THERMISTOR 843032 1
Z201,Z203 * RNET,MF,HERM,SIP,5700 LO V INS 809418 2
