Fluke 5725A - Page 163

List of Replaceable Parts
Parts Lists
8
8-23
Table 8-5. A3 High Voltage Amplifier PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
R640,R642 RES,CF,100K,+-5%,0.25W 348920 2
R641,R648 RES,MF,10K,+-1%,0.125W,100PPM 168260 2
R643 RES,CF,4.7M,+-5%,0.25W 543355 1
R647 RES,MF,20K,+-1%,0.125W,100PPM 291872 1
R651 RES,CC,220,+-10%,1W 109462 1
R654,R661,R684,
R692
RES,LERM,100K,+-5%,3W 820811
820811
4
R657,R658,R666,
R667,R676,R677,
R686,R687
RES,MDX,3.9,+-1%,1W,200PPM
687852
687852
687852
8
R668,R669 RES,CF,20K,+-5%,0.25W 441477 2
R670-673 RES,CF,0.51,+-5%,0.25W 381954 4
R695 RES,CF,10M,+-5%,.25W 875257 1
RT663 ASSY, THERMISTOR 843032 1
TP601-616 JUMPER,WIRE,NONINSUL,0.200CTR 816090 16
U601,U603 * IC,OP AMP,DUAL,LO OFFST,VOLT,L 685164 2
U602 * IC,OP AMP,HIGH SPEED,200V/US,3 845466 1
U604 * IC,COMPARATOR,QUAD,14 PIN DIP 387233 1
U605 * ISOLATOR,OPTO,LED TO PHOTO-RES 887062 1
U606 * IC,COMPARATOR,DUAL,LO-PWR,8 PI 478354 1
VR601 * ZENER,UNCOMP,24.0V,5%,5.2MA,0. 267807 1
VR602,VR658 * ZENER,UNCOMP,6.8V,5%,20.0MA,0. 260695 2
VR603,VR666 * ZENER,UNCOMP,5.1V,5%,20.0MA,0. 159798 2
VR651,VR665 * ZENER,UNCOMP,15.0V,5%,8.5MA,0. 266601 2
VR652-
657,VR659-662
*
*
ZENER,UNCOMP,10.0V,5%,12.5MA,0
246611
246611
10
VR663,VR664 * ZENER,UNCOMP,20.0V,5%,12.5MA,1 291575 2
