Fluke 5725A - Page 172

5725A
Instruction Manual
8-32
Table 8-8. A6 High Voltage Sense PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
J403 HEADER,1 ROW,.156CTR,RT ANG,5 844717 1
K101,K106-108,
K111,K151-153
RELAY,ARMATURE,2 FORM C,5V 733063
733063
8
K102-105,K109 RELAY,REED,1 FORM A,5VDC 806950 5
K401 RELAY,ARMATURE,2 FORM A,5VDC 830547 1
L100-105 CHOKE, 3 TURN 452888 6
MP1 CABLE ACCESS,TIE,4.00L,.10W,.7 172080 2
MP25 SHIELD, DIGITAL 842930 1
MP26 SHIELD, SENSOR 842935 1
MP27 INSULATOR, SENSE 843099 1
MP36 SUPPORT,ATTENUATOR 823195 2
MP038 BUMPER, HI-TEMP 1601870 1
MP81 CLAMP,PWB MOUNTING 823039 1
MP82 CLAMP,PWB MOUNTIN 842948 1
MP101 AIDE,PCB PULL 541730 2
MP813 WIRE, ATTENUATOR 843094 1
Q100,Q102 * TRANSISTOR,SI,PNP,80V,0.625W,T 816272 2
Q101,Q103 * TRANSISTOR,SI,NPN,SMALL SIGNAL 816298 2
Q104,Q107,Q401 * TRANSISTOR,SI,N-MOS,350MW,TO-9 783449 3
Q105 * TRANSISTOR,SI,PNP,40V,0.35W,TO 698233 1
Q106,Q150 * TRANSISTOR,SI,NPN,SMALL SIGNAL 698225 2
R100,R123,R124,
R157,R159-161,
R163-167,R177
RES,CF,1.5K,+-5%,0.25W 810432
810432
810432
13
R101,R102 RES,MF,86.6K,+-1%,0.125W,100PP 772046 2
R103 RES,MF,40.2K,+-1%,2W,10PPM 811042 1
R104,R108,R116 RES,CF,330,+-5%,0.25W 830596 3
R105,R114 RES,MF,2K,+-1%,0.125W,100PPM 816629 2
R106 RES,MF,402K,+-0.1%,0.125W,100P 714329 1
R107,R117 RES,CF,240,+-5%,0.25W 830588 2
R110,R113,R115,
R119,R121,R122,
R128,R129,R150
RES,CF,47,+-5%,0.25W
822189
822189
822189
9
R112 RES,MF,1.21K,+-1%,0.125W,100PP 810507 1
R118 RES,CF,4.7,+-5%,0.25W 816637 1
R120,R170 RES,MF,619,+-0.1%,0.125W,100PP 810515 2
R125,R174,R179 RES,CF,100K,+-5%,0.25W 658963 3
R126 RES,CF,3.9,+-5%,0.25W 810473 1
R127 RES,CF,20K,+-5%,0.25W 697110 1
R130 RES,CF,100,+-5%,0.25W 810465 1
R131,R132 RES,MF,2.67K,+-1%,0.125W,100PP 820290 2
R133,R134 RES,MF,1K,+-1%,0.125W,100PPM 816595 2
R151,R169 RES,MF,18.2K,+-1%,0.125W,100PP 756429 2
R153 RES,MF,80.27K,+-0.1%,0.125W,25 851337 1
