7008
Users Guide
9-6
9.4 Temperature Scale Units
The temperature scale units of the controller may be set by the user to degrees
Celsius ( °C) or Fahrenheit ( °F). The units will be used in displaying the bath
temperature, set-point, vernier, proportional band, and cut-out set-point.
The temperature scale unit’s selection is accessed after the vernier adjustment
function by pressing “SET”. From the temperature display function accesses the
unit’s selection by pressing “SET” 4 times.
25.00 C Bath temperature
Access set-point memory
1. 25.0 Set-point memory
Access set-point value
C 40.00 Set-point value
Access vernier
0.00000 Vernier setting
Access scale units selection
Un= C Scale units currently selected
Press “UP” or “DOWN” to change the units.
Un= F New units selected
Press “SET” to accept the new selection and resume displaying the bath
temperature.
Set the new units and resume temperature display
