712B/714B
Calibration Manual
Required Equipment
The equipment listed in Table 2 is necessary to do the calibration and test for the
712B. The equipment listed in Table 3 is necessary to do the calibration and test
for the 714B.
Note
Fluke 5522A and Fluke 8508A need an 8-hour warmup period
before the calibration starts. The 5522A needs to zero all the
functions weekly and zero Ohms output function every day. The
8508A needs to zero the dc V measurement function, the 4-Wire
Ohms measurement function and the DCI measurement function.
Table 2. Required Equipment for 712B Verification and Calibration Adjustment
Item Equipment QTY Comment
Fluke 5522A 1 ——
Fluke 8508A 1
Can be replaced with other
reference or equivalent
DMMs
B-36-2,BANANA PLUG
PATCH CORD (Part
number:1894785, RED, Part
number: 1894724, BLACK)
Or
Fluke-75X-8014,
STACKABLE LEAD SET
(Part number: 3669716)
2 sets
Used for all the function
calibration and verification
test
Table 3. Required Equipment for 714B Verification and Calibration Adjustment
Item Equipment QTY Comment
Fluke 5522A 1 The mV output should be calibrated by 8508A
[1]
.
Fluke 8508A 1
Can be replaced with other reference or
equivalent DMMs
[2]
.
Fluke 9101-256 1
Can be replaced with a lag bath and standard
sensors
[3]
Pure copper cables
with the mini plug
1
Used for the calibration of the mV input function
and mV source function
J TYPE and K TYPE
TC Sensor
[4]
1
Used for verification and calibration adjustment
of the temperature function
Fluke-75X-8014 1 Fluke Item No: 3669716
Fluke 7526A 1 -
[1]
[2]
[3]
[4]
Before using the mV output function of 5522A, record the 5522A output setting by the reading of the
8508A.
The absolute uncertainties of the DMM’s dc voltage need to be better than 10 ppm+0.2 μV in the range of
0 mV and 100 mV.
The accuracy (MAX) of standard sensors should be better than 0.05 °C.
The accuracy (MAX) of the TC sensor should be better than 0.05 °C.
10
