Required Equipment
23
Table 6. Required Equipment and Software
Equipment Minimum Specifications Recommended Model
Multi-Product Calibrator
DC voltage: 0 V to 30 V
Accuracy: ±0.005 %
DC current: 0 mA to 24 mA
Accuracy: ±0.005 %
Temperature: Type-J thermocouple
90 day accuracy: ±0.2 °C
Resistance accuracy: ±0.006 %
Frequency accuracy: ±0.01 %
Fluke Model 5520A Multi-Product
Calibrator only−no substitute
MET/CAL
®
Metrology
Software
(see MET/CAL
Installation and Upgrade
Guide for minimum
hardware requirements)
Version 6.0 or later Contact Fluke for the latest version.
Digital Multimeter
DC voltage: 0 V to 24 V
Accuracy: ±0.0013 %
DC voltage: 0 mA to 24 mA
Accuracy: ±0.005 %
Fluke 8508A
Pressure Module
(725 and 726)
In working condition; for establishing
communication only
Fluke 700PXX Series
Test Leads Two sets of stackable low thermal
EMF banana test leads
2 red leads: Fluke PN 105809
2 black leads: Fluke PN 105806
Thermocouple Test
Lead
2 Type-J male miniplugs with ~12”
(30.5 cm) of 20-gauge Type-J
thermocouple wire
Fluke Model 80CJ-M male miniplugs
(package of two)
20-gauge Type-J thermocouple wire
is available through an electronic
supply outlet
Personal computer Windows
®
3.1 or later with terminal
communication software
486 (or later) IBM-compatible
PC interface cable
(725 and 726)
Fluke 700SC serial interface cable
assembly (LEMO to DB-9 female)
Fluke PN 667425
Calibration cable Fluke 724/725 Calibration Cable Fluke PN 1556747
Standard Thermometer 0.1 % accuracy
