COMMAND REFERENCE 4 - 23
*
RST Reset
Syntax:
*
RST
Description:
The
*
RST command resets the instrument. The hardware and software of the
instrument is initialized without affecting any of the IEEE interface conditions. The
instrument turns into a fixed setup, which is optimized for remote operation. This
fixed setup is different from the setup that can be recalled via the front panel
softkeys and the SETUPS menu, which is optimized for local control.
The
*
RST command affects the following:
•
Sets the following instrument settings, independent of the past history:
FUNCTION:
DEFAULT SETTING(S):
Digital mode
X-deflection (X vs Y)
Delayed Time Base
Main Time Base
X-magnify factor
Channel 1 ON
Channels 2, 3 and 4
Trigger
TB mode
ON
OFF
OFF
Sweep time 10 ms (total acquisition)
Autoranging OFF
x1
200 mV/div
DC coupled
Position centred
Impedance 1 M
Ω
(without probe)
OFF
Polarity NORMal (INV OFF)
add1+2 (CH1+CH2) OFF
add3+4 (CH3+CH4) OFF
Type EDGE
Source IMMediate
Slope POSitive
Level-pp OFF
Noise ON
Level MAXimum (± 1.64 V)
DC signal coupling
Video mode ALL (lines)
Video signal polarity POSitive
625 video lines per frame
Video line/field = 1/1
Hold-off time = 0
Low-pass filter ON
Low-pass cutoff frequency 0 Hz (DC coupling)
High-pass filter OFF
High-pass cutoff frequency bandwidth (100/200 MHz)
Single shot
Roll mode OFF
