4 - 48 COMMAND REFERENCE
DISPlay:WINDow[1]:TEXT<n>:DATA?
Syntax:
DISPlay:WINDow[1]:TEXT<n>:DATA?
[1] Indicates that the measurement result field is window 1.
<n> 1 | 2 | 10 | 11 | 12 | 13 | 20 | 21 | 30 | 40 | 51 | 52 | 60 | 61
1 MEAS1 result is returned.
2 MEAS2 result is returned.
10 Delta-V/Delta-Y is returned under the following conditions:
11 V1 is returned.
12 V2 is returned.
13 DC voltage (VDC) is returned.
20 Delta-T is returned under the following conditions:
21 Frequency (1 / delta-T) is returned.
30 Delta-X is returned under the following conditions:
40 The phase between 2 channels is returned.
51 T1-trg is returned.
52 T2-trg is returned.
60 FFT frequency in Hz is returned.
61 FFT amplitude is returned expressed in:
- dB (relative value)
- dBm, dbµV, or Vrms (absolute value)
Response:
<ASCII_data>
<ASCII_data> A sequence of 7-bit ASCII characters.
Example:
Send
→
DISPlay:WINDow:TEXT1:DATA?
Read
←
pkpk,6084E-04,V
Response is peak-peak value of 608.4 mV
(MEAS1).
Description:
The DISPlay:WINDow[1]:TEXT<n>:DATA? query returns the measured data as
displayed on the upper line(s) of the screen of your CombiScope instrument.
TYPE: ANALOG MODE: DIGITAL MODE:
Delta-V
Delta-Y
X-deflection off
X-deflection on
X versus Y off
X versus Y on
TYPE: ANALOG MODE: DIGITAL MODE:
Delta-T X-deflection off X versus Y off
TYPE: ANALOG MODE: DIGITAL MODE:
Delta-X X-deflection on X versus Y on
