B - 20 CROSS REFERENCES
FUNCTION + KEYS/MENUS
RELATED SCPI COMMAND(S)
FFT - FAST FOURIER TRANSFORMATION (MATHPLUS)
key MATH
SYSTem:KEY 111
menu MATH
DISPlay:MENU MATH
-
softkeys n=1 .. 6
SYSTem:KEY n
-
MATH1(2) FFT ON/OFF
CALCulate[1|2]:TRANsform:FREQuency:STATE
-
PARAM select FFT windows
CALCulate[1|2]:TRANsform:FREQuency:
WINDow RECTangular|HAMMing|HANNing
-
read FFT amplitude/frequency
DISPlay:WINDow[1]:TEXT<n>:DATA?
-
select absolute/relative FFT
CALCulate[1/2]:TRANsform:FREQuency:TYPE
FILTER (MATHEMATICS)
key MATH
SYSTem:KEY 111
menu MATH
DISPlay:MENU MATH
-
softkeys n = 1 .. 6
SYSTem:KEY n
-
MATH1(2) filter ON/OFF
CALCulate[1|2]:FILTer:FREQuency:STATe
-
PARAM window samples
CALCulate[1|2]:FILTer:FREQuency:POINts
GLITCH triggering
TRIGger:TYPE GLITch
HISTOGRAM (MATHPLUS)
key MATH
SYSTem:KEY 111
menu MATH
DISPlay:MENU MATH
-
softkeys n=1 .. 6
SYSTem:KEY n
-
MATH1(2) histogram ON/OFF
CALCulate[1|2]:TRANsform:HISTogram:STATe
HOLD OFF
TRIGger:HOLDoff
Identification
*
IDN?
and
*
OPT?
SYSTem:VERSion?
INPUT ATTENUATOR
SENSe:VOLTage<n>[:DC]:RANGe:PTPeak
key AUTO RANGE channel <n>
SENSe:VOLTage<n>[:DC]:RANGe:AUTO
key AMPL mv ( )
CH1
SYSTem:KEY 702
key AMPL v ( )
CH1
SYSTem:KEY 802
key AMPL mv ( )
CH2
SYSTem:KEY 705
key AMPL v ( )
CH2
SYSTem:KEY 805
key AMPL mv ( )
CH3
SYSTem:KEY 708 (PM33x4B)
key AMPL v ( )
CH3
SYSTem:KEY 808 (PM33x4B)
key AMPL mv ( )
CH4
SYSTem:KEY 711 (PM33x4B)
key AMPL v ( )
CH4
SYSTem:KEY 811 (PM33x4B)
key AMPL
EXT
(CH4)
SYSTem:KEY 712 (PM33x0B)
