CROSS REFERENCES B - 21
FUNCTION + KEYS/MENUS
RELATED SCPI COMMAND(S)
INPUT COUPLING
INPut[<n>]:COUPling AC|DC|GROund
key ON (toggled ON)
SENSe:FUNCtion
key ON CH1
SYSTem:KEY 803
key ON CH2
SYSTem:KEY 806
key ON CH3
SYSTem:KEY 809 (PM33x4B)
key ON CH4
SYSTem:KEY 812 (PM33x4B)
key TRIG VIEW EXT
SYSTem:KEY 812 (PM33x0B)
key AC/DC/GND
CH1
SYSTem:KEY 804
key AC/DC/GND
CH2
SYSTem:KEY 807
key AC/DC/GND
CH3
SYSTem:KEY 810 (PM33x4B)
key AC/DC/GND
CH4
SYSTem:KEY 813 (PM33x4B)
key AC/DC
EXT
SYSTem:KEY 813 (PM33x0B)
INPUT IMPEDANCE
INPut[<n>]:IMPedance
key VERT MENU
SYSTem:KEY 504
menu VERT MENU
DISPlay:MENU VERTical
-
50
Ω
CH<n>
INPut<n>:IMPedance
INTEGRATE (MATHPLUS)
key MATH
SYSTem:KEY 111
menu MATH
DISPlay:MENU MATH
-
softkeys n=1 .. 6
SYSTem:KEY n
-
MATH1(2) integrate ON/OFF
CALCulate[1|2]:INTegral:STATe
LOGIC TRIGGER
TRIGger:TYPE LOGic
key TRIGGER
SYSTem:KEY 209
menu TRIGGER
DISPlay:MENU TRIGger
-
softkeys n = 1 .. 6
SYSTem:KEY n
-
TRIG slope
TRIGger:SLOPe
-
TRIG source
TRIGger:SOURce
MAGNIFY HORIZONTAL
key MAGNIFY ( )
SYSTem:KEY 210
key MAGNIFY ( )
SYSTem:KEY 211
MAGNIFY VERTICAL
key DISPLAY
SYSTem:KEY 112
menu DISPLAY
DISPlay:MENU DISPlay
-
softkeys n = 1 .. 6
SYSTem:KEY n
MAIN TIME BASE
SENSe:SWEep:TIME
key TIME/DIV VAR s
SYSTem:KEY 410
key TIME/DIV VAR ns
SYSTem:KEY 411
key AUTO RANGE
SENSe:SWEep:TIME:AUTO
