FMC Technologies Smith Meter AccuLoad II Programming Workbook

Program Program
Code Function Code Description Entry Code
18 AB06030 Rev. 0.6 5/96
446 Minimum Density Enter: Five (5) digits. For 446
OR Minimum minimum density at 4 mA in
Temperature tenth units (e.g., 0100.0).
as selected in For minimum Temperature at 4 mA the
code 444 first digit indicates the polarity.
First digit "0" = Positive
First digit "1" = Negative
The last four digits indicate the
temperature in tenth degrees.
(e.g., 0030.0 = +030.0)
Temperature units as selected
in code 441. __ __ __ __ . __
447 Maximum Density Enter: Five (5) digits. For 447
OR Maximum maximum density at 20 mA in
Temperature tenth units (e.g., 1600.0).
as selected For maximum Temperature at 4 mA the
in code 444 first digit indicates the polarity.
First digit "0" = Positive
First digit "1" = Negative
The last four digits indicate the
temperature in tenth degrees.
(e.g., 0100.0 = +100.0)
Temperature units as selected
in code 441. An entry of -999.9
(Temperature) or 0000.0 (Density)
will disable this feature. __ __ __ __ . __
448 Volume/Mass Enter: "0" Gallons per Density Units 448
Conversion "1" Dekaliters per Density Units
"2" Liters per Density Units
"3" Barrels per Density Units
"4" Cubic Meters per Density Units __
449 Mass Units Enter: Three (3) character message 449
identifying the mass units
(e.g., Lbs) __ __ __
450-499 Unassigned at Present 450-499
500
System Pressure Directory
500
501-539 Unassigned at Present 501-539
540 Protection of Program Enter: "0" for Weights and Measures Mode 540
Codes 580-589 "1" for Program Mode __
541 Pressure Units Enter: "0" No Pressure Transducer Installed 541
"1" Psi
"2" Bar
"3" Kgcm __
542 Minimum Pressure Enter: Four (4) digits in tenth 542
Units units for minimum pressure
at 4 mA. (e.g., 1600 = 160.0)
Units dependent on selection
in code 541. __ __ __ . __
