FMC Technologies Smith Meter AccuLoad II Programming Workbook

Program Program
Code Function Code Description Entry Code
2 AB06030 Rev. 0.6 5/96
System Directories
000 System Configuration Directory 000
001 Number of Products Enter: "1" One (1) Product 001
"2" Two (2) Products
"3" Three (3) Products
"4" Four (4) Products __
002 Number of Additive Enter: "0" No Additive Injectors 002
Injectors "1" One (1) Additive Injector
"2" Two (2) Additive Injectors
"3" Three (3) Additive Injectors
"4" Four (4) Additive Injectors
"5" Five (5) Additive Injectors
"6" Six (6) Additive Injectors
"7" Seven (7) Additive Injectors __
003 A/C Output Relay 1 Enter: "00" No Assignment (NAS) 003
Terminals 89 & 90 "01" Alarm Relay (ALR)
(Position #1) "02" Additive Relay 1 (ADD1)
Terminals 124 & 125 "03" Additive Relay 2 (ADD2)
(Position #2) "04" Additive Relay 3 (ADD3)
"05" Additive Relay 4 (ADD4)
"06" Additive Relay 5 (ADD5)
"07" Additive Relay 6 (ADD6)
"08" Additive Relay 7 (ADD7)
"09" Block Valve Relay 1 (BVR1)
"10" Block Valve Relay 2 (BVR2)
"11" Block Valve Relay 3 (BVR3)
"12" Block Valve Relay 4 (BVR4)
"13" General Relay (GEN)
"14" First Trip Indicator (FTR) __ __
Note:
1. Option "14" First Trip Indicator of this code applies to SEQ-06 and above firmware.
2. When using a Smart Additive Subsystem, options 02 through 08 (Additive Relays) are not available for selection.
004 A/C Output Relay 2 Enter: "00" No Assignment (NAS) 004
Terminals 91 & 92 "01" Alarm Relay (ALR)
(Position #1) "02" Additive Relay 1 (ADD1)
Terminals 126 & 127 "03" Additive Relay 2 (ADD2)
(Position #2) "04" Additive Relay 3 (ADD3)
"05" Additive Relay 4 (ADD4)
"06" Additive Relay 5 (ADD5)
"07" Additive Relay 6 (ADD6)
"08" Additive Relay 7 (ADD7)
"09" Block Valve Relay 1 (BVR1)
"10" Block Valve Relay 2 (BVR2)
"11" Block Valve Relay 3 (BVR3)
"12" Block Valve Relay 4 (BVR4)
"13" General Relay (GEN)
"14" First Trip Indicator (FTR) __ __
Note:
1. Option "14" First Trip Indicator of this code applies to SEQ-06 and above firmware.
2. When using a Smart Additive Subsystem, options 02 through 08 (Additive Relays) are not available for selection.
