FMC Technologies Smith Meter AccuLoad II Programming Workbook

Program
Code Function Code Description Prod 1 Prod 2 Prod 3 Prod 4
AB06030 Rev. 0.6 5/96 33
Product Directories
100
Product General Purpose Directory
101-139 Unassigned at Present
140 Protection of Program Enter: "0" for Weights and Measures Mode
Codes 180 - 189 "1" for Program Mode __ __ __ __
141 Product Selection Enter: "0" for Product in Use
"1" for Product Not in Use __ __ __ __
142-179 Unassigned at Present
180 Product Message Enter: Up to nine (9) characters
for meter or product
identifier (e.g., Regular) Prod 1___________________________
Prod 2___________________________
Prod 3___________________________
Prod 4___________________________
181-199 Unassigned at Present
200
Product Flow Control Directory
201 Excess Flow Rate Enter: Two (2) digits as a percentage
(e.g., 10) "00" Disables the High
Flow Alarm __ __ __ __ __ __ __ __
202 Minimum Flow Rate Enter: Three (3) digits in whole units
(e.g., 080) __ __ ____ __ ____ __ __ __ __ __
203 Block Valve Type Enter: "0" Hydraulic Block Valve
"1" Electric Block Valve __ __ __ __
204 First High Flow Rate Enter: Four (4) digits in whole units
(e.g., 0600) "0000" Entry will not
allow the valve to open _____ _____ _____ _____
205 Flow Tolerance Enter: One (1) digit as a percentage of
First High Flow Rate (e.g., 7) __ __ __ __
206 Second High Flow Enter: Four (4) digits in whole units
Rate (e.g., 0300) "0000" Entry will not
allow the valve to open if
configured for 1st/2nd High Flow. _____ _____ _____ _____
207 First Trip Volume Enter: Four (4) digits in whole units
(e.g., 0050) _____ _____ _____ _____
208 Final (Second) Trip Enter: Three (3) digits in tenth units
Volume (e.g., 01.0) ___._ ___._ ___._ ___._
209 Final (Second) Trip Enter: One (1) digit which defines
Auto Adjust the number of runs to average.
(e.g., 3) __ __ __ __
210 Low Flow Rate Alarm Enter: Three (3) digits in whole
Limit units per minute (e.g., 050)
"000" disables the alarm ____ ____ ____ ____
211 Block Valve Delay Enter: Two (2) digits in
to Close seconds of delay time
(e.g., 05) ___ ___ ___ ___
