FMC Technologies Smith Meter AccuLoad II Programming Workbook

Program Program
Code Function Code Description Entry Code
AB06030 Rev. 0.6 5/96 3
005 A/C Output Relay 3 Enter: "00" No Assignment (NAS) 005
Terminals 93 & 94 "01" Alarm Relay (ALR)
(Position #1) "02" Additive Relay 1 (ADD1)
Terminals 128 & 129 "03" Additive Relay 2 (ADD2)
(Position #2) "04" Additive Relay 3 (ADD3)
"05" Additive Relay 4 (ADD4)
"06" Additive Relay 5 (ADD5)
"07" Additive Relay 6 (ADD6)
"08" Additive Relay 7 (ADD7)
"09" Block Valve Relay 1 (BVR1)
"10" Block Valve Relay 2 (BVR2)
"11" Block Valve Relay 3 (BVR3)
"12" Block Valve Relay 4 (BVR4)
"13" General Relay (GEN)
"14" First Trip Indicator (FTR) __ __
Note: 1. Option "14" First Trip Indicator of this code applies to SEQ-06 and above firmware.
2. When using a Smart Additive Subsystem, options 02 through 08 (Additive Relays) are not available for selection.
006 A/C Output Relay 4 Enter: "00" No Assignment (NAS) 006
Terminals 95 & 96 "01" Alarm Relay (ALR)
(Position #1) "02" Additive Relay 1 (ADD1)
Terminals 130 & 131 "03" Additive Relay 2 (ADD2)
(Position #2) "04" Additive Relay 3 (ADD3)
"05" Additive Relay 4 (ADD4)
"06" Additive Relay 5 (ADD5)
"07" Additive Relay 6 (ADD6)
"08" Additive Relay 7 (ADD7)
"09" Block Valve Relay 1 (BVR1)
"10" Block Valve Relay 2 (BVR2)
"11" Block Valve Relay 3 (BVR3)
"12" Block Valve Relay 4 (BVR4)
"13" General Relay (GEN)
"14" First Trip Indicator (FTR) __ __
Note: 1. Option "14" First Trip Indicator of this code applies to SEQ-06 and above firmware.
2. When using a Smart Additive Subsystem, options 02 through 08 (Additive Relays) are not available for selection.
007 A/C Output Relay 5 Enter: "00" No Assignment (NAS) 007
Terminals 87 & 88 "01" Alarm Relay (ALR)
(Position #1) "02" Additive Relay 1 (ADD1)
Terminals 121 & 122 "03" Additive Relay 2 (ADD2)
(Position #2) "04" Additive Relay 3 (ADD3)
"05" Additive Relay 4 (ADD4)
"06" Additive Relay 5 (ADD5)
"07" Additive Relay 6 (ADD6)
"08" Additive Relay 7 (ADD7)
"09" Block Valve Relay 1 (BVR1)
"10" Block Valve Relay 2 (BVR2)
"11" Block Valve Relay 3 (BVR3)
"12" Block Valve Relay 4 (BVR4) __ __
Note: When using a Smart Additive Subsystem, options 02 through 08 (Additive Relays) are not available for selection.
