17
Physical and Electrical Characteristics
Analogue Inputs
Connectors “Combo XLR” sockets: Mic/Line/Inst, on front panel
Mic/Line switching Automatic
Line/Instrument switching via Focusrite Control
Phantom power +48 V switches for each input
Analogue Outputs
Main outputs 4 x balanced ¼” TRS jacks (on rear panel)
Stereo headphone output ¼” TRS jack on front panel
Main monitor output level control
On front panel
Headphones level control
Other I/O
ADAT I/O
TOSLINK optical connector:
8 channels at 44.1/48 kHz
4 channels at 88.2/96 kHz
2 channels at 176.2/192 kHz
Optical S/PDIF input (selectable up to 96kHz)
Data connector (to Mac) 1 x Thunderbolt connector
MIDI I/O 2 x 5-pin DIN sockets
Weight and Dimensions
W x D x H 210 mm x 161 mm x 55 mm / 8.27” x 6.34” x 2.17”
Weight
1.36 kg
3.00 lbs
