PERFORMANCE SPECIFICATIONS
Inputs
AES/EBU inputs 8 channels, with switchable SRC
AES/EBU connector 25-way female Dsub, wired to AES 59 (combined I/O)
ADAT inputs
32 channels @ 44.1 / 48 / 88.2 / 96 kHz sample rate; 16 channels @
192 kHz
ADAT connectors TOSLINK lightguides x 8
S/PDIF input 2 channels, with switchable SRC 44.1 to 192 kHz
S/PDIF connector Phono (RCA) socket
AES/EBU Input Sampe Rate Converters
Input sample rate range 32 to 216 kHz
Gain error -0.3 dB
Dynamic Range > 138 dB (-60 dBFS method)
THD+N < -130 dB (0.00003%); 0 dBFS input
Outputs
AES/EBU outputs 8 channels, sync-locked to RedNet system sample rate
AES/EBU connector See “Inputs”
ADAT outputs
32 channels @ 44.1 / 48 / 88.2 / 96 kHz sample rate; 16 channels @
192 kHz
ADAT connectors TOSLINK lightguides x 8
S/PDIF output 2 channels, sync-locked to RedNet system sample rate
S/PDIF connector Phono (RCA) socket
Operating Modes
AES/EBU mode
AES/EBU inputs – Chs. 1 to 8; ADAT inputs – Chs. 9 to 32*; AES/EBU
outputs – Chs. 1 to 8; ADAT outputs – Chs. 1 to 32*
ADAT mode
ADAT inputs – Chs. 1 to 32*; AES/EBU outputs – Chs. 1 to 8; ADAT
outputs – Chs. 1 to 32*
Digital Performance
Supported sample rates 44.1 / 48 / 88.2 / 96 / 192 kHz
Clock sources Local or from network master device
Local clock sources Internal, Word Clock input, AES input 1, ADAT input 1, S/PDIF input
External word clock range Sample rate ±7.5%
Power
PSU Internal, 100 - 240 V, consumption 30 VA
* Sample rate dependent – max. 16 channels at 192 kHz
