34 01134592 – REF20/25 LB, PH, BB
Cabinet
1
5
6
8
7
9
2
9
4
3
Reference Description Part #
1 Caster, swivel with brake 00187674
2 Bracket, bottle, 125 ml 00171132
3 Drawer, assembly, REF25 00939652
3 Drawer, assembly, REF20 00939660
4 Slide, drawer, REF25 (set of 2) 00193045
4 Slide, drawer, REF20 (set of 2) 00188367
5 Bottle with gasket 01015817
Not shown Basket, assembly, REF25 00939710
Not shown Basket, assembly, REF20 00939728
6 Shelf, REF25 (with supports) 01015841
6 Shelf, REF20 (with supports) 01015858
7 Pilaster 00901173
Not shown Pilaster, screws 00902213
8 Support, shelf 00156240
Not shown Air panel 01234558
Not shown Temperature probe, top/bottom, NIST calibrated 01140458
Not shown RTD Probe retro t kit 01313915
9 Cover, thermal break (4 pieces) 00922997
Not shown LED, light strip 00980912
Not shown Wire clip, probe 00919910
Not shown Glycerine (1 pint) 00959296
Not shown LEDs (2), MOV and instructions 01049709
Not shown CPI to Touchscreen retrot probe 01151562
